Fixed Inductors
Use the filters and product table below to compare Fixed Inductors components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PM42S-2R7FIXED IND 2.7UH 1.28A 105MOHM SM |
1,640 | - |
|
Datasheet | PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 2.7 µH | ±30% | 1.28 A | - | Shielded | 105mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-390FIXED IND 39UH 300MA 709MOHM SMD |
3,975 | - |
|
Datasheet | PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 39 µH | ±30% | 300 mA | - | Shielded | 709mOhm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-3R3FIXED IND 3.3UH 1.04A 110MOHM SM |
1,954 | - |
|
Datasheet | PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 1.04 A | - | Shielded | 110mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-560FIXED IND 56UH 260MA 1.08OHM SMD |
4,844 | - |
|
Datasheet | PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 56 µH | ±30% | 260 mA | - | Shielded | 1.08Ohm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-5R6FIXED IND 5.6UH 800MA 170MOHM SM |
1,359 | - |
|
Datasheet | PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 5.6 µH | ±30% | 800 mA | - | Shielded | 170mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-820FIXED IND 82UH 220MA 1.56OHM SMD |
3,266 | - |
|
Datasheet | PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 82 µH | ±30% | 220 mA | - | Shielded | 1.56Ohm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-8R2FIXED IND 8.2UH 680MA 245MOHM SM |
3,252 | - |
|
Datasheet | PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 8.2 µH | ±30% | 680 mA | - | Shielded | 245mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
PM43-1R0MFIXED IND 1UH 2.56A 49 MOHM SMD |
1,462 | - |
|
Datasheet | PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1 µH | ±20% | 2.56 A | - | Unshielded | 49mOhm | - | 113MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-1R4MFIXED IND 1.4UH 2.52A 57MOHM SMD |
4,554 | - |
|
Datasheet | PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.4 µH | ±20% | 2.52 A | - | Unshielded | 57mOhm | - | 101MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-1R8MFIXED IND 1.8UH 1.95A 64MOHM SMD |
1,385 | - |
|
Datasheet | PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.8 µH | ±20% | 1.95 A | - | Unshielded | 64mOhm | - | 92MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
Fixed Inductors FAQ
Common questions about filtering, comparing and sourcing Fixed Inductors components.
How can I narrow the Fixed Inductors selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Fixed Inductors part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
