IGBT Modules
Use the filters and product table below to compare IGBT Modules components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BSM75GAL120DN2HOSA1IGBT MOD 1200V 105A 625W |
4,753 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Single Switch | 1200 V | 105 A | 625 W | 3V @ 15V, 75A | 1.4 mA | 5.5 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount | Module |
|
|
BSM75GB120DN2HOSA1IGBT MOD 1200V 105A 625W |
2,107 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Half Bridge | 1200 V | 105 A | 625 W | 3V @ 15V, 75A | 1.5 mA | 5.5 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount | Module |
|
|
BSM75GD120DN2BOSA1IGBT MOD 1200V 103A 520W |
2,275 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Three Phase Inverter | 1200 V | 103 A | 520 W | 3V @ 15V, 75A | 1.5 mA | 5.1 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount | Module |
|
|
BSM75GD60DLCBOSA1IGBT MODULE 600V 95A 330W |
3,053 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Full Bridge | 600 V | 95 A | 330 W | 2.45V @ 15V, 75A | 500 µA | 3.3 nF @ 25 V | Standard | No | -40°C ~ 125°C | Chassis Mount | Module |
|
BYM600A170DN2HOSA1IGBT MODULE 1400W MED PWR 62MM-2 |
6,442 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Single | - | - | 1400 W | - | - | - | Standard | No | 150°C (TJ) | Chassis Mount | Module |
|
DDB6U100N16RRBOSA1IGBT MOD 1200V 50A 350W |
5,049 | - |
|
Datasheet | - | Module | Tray | Discontinued at Digi-Key | - | Single Chopper | 1200 V | 50 A | 350 W | 3.2V @ 20V, 50A | 1 mA | 3.3 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount | Module |
|
|
F4100R06KL4BOSA1IGBT MOD 600V 130A 430W |
3,923 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Half Bridge | 600 V | 130 A | 430 W | 2.55V @ 15V, 100A | 5 mA | 4.3 nF @ 25 V | Standard | Yes | -40°C ~ 125°C | Chassis Mount | Module |
|
|
F4150R06KL4BOSA1IGBT MOD 600V 180A 570W |
2,465 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Full Bridge | 600 V | 180 A | 570 W | 2.55V @ 15V, 150A | 5 mA | 6.5 nF @ 25 V | Standard | Yes | -40°C ~ 125°C | Chassis Mount | Module |
|
F4150R17ME4B11BPSA1IGBT MODULE 1700V 230A |
6,560 | - |
|
Datasheet | EconoDUAL™ 3 | Module | Tray | Discontinued at Digi-Key | Trench Field Stop | Full Bridge | 1700 V | 230 A | - | 2.3V @ 15V, 150A | 3 mA | 12 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount | Module |
|
|
F4200R06KL4BOSA1IGBT MOD 600V 225A 695W |
7,404 | - |
|
Datasheet | - | Module | Tray | Obsolete | - | Full Bridge | 600 V | 225 A | 695 W | 2.55V @ 15V, 200A | 5 mA | 9 nF @ 25 V | Standard | No | -40°C ~ 125°C | Chassis Mount | Module |
