IGBT Modules
Use the filters and product table below to compare IGBT Modules components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IXSN50N60BD2IGBT MOD 600V 75A 250W SOT227B |
6,917 | - |
|
Datasheet | - | SOT-227-4, miniBLOC | Tube | Obsolete | - | Single | 600 V | 75 A | 250 W | 2.5V @ 15V, 50A | 350 µA | 3.85 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | SOT-227B |
|
|
IXSN55N120AU1IGBT MOD 1200V 110A 500W SOT227B |
7,052 | - |
|
Datasheet | - | SOT-227-4, miniBLOC | Tube | Obsolete | - | Single | 1200 V | 110 A | 500 W | 4V @ 15V, 55A | 1 mA | 8 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Chassis Mount | SOT-227B |
|
|
IXSN62N60U1IGBT MOD 600V 90A 250W SOT227B |
4,513 | - |
|
Datasheet | - | SOT-227-4, miniBLOC | Tube | Obsolete | PT | Single | 600 V | 90 A | 250 W | 2.5V @ 15V, 50A | 750 µA | 4.5 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Chassis Mount | SOT-227B |
|
IXSN80N60AU1IGBT MOD 600V 160A 500W SOT227B |
7,408 | - |
|
Datasheet | - | SOT-227-4, miniBLOC | Tube | Obsolete | - | Single | 600 V | 160 A | 500 W | 3V @ 15V, 80A | 1 mA | 8.5 nF @ 25 V | Standard | No | -55°C ~ 150°C (TJ) | Chassis Mount | SOT-227B |
|
MIXA101W1200EHIGBT MODULE 1200V 155A 500W E3 |
7,292 | - |
|
Datasheet | - | E3 | Box | Active | PT | Three Phase Inverter | 1200 V | 155 A | 500 W | 2.1V @ 15V, 100A | 300 µA | - | Standard | No | -40°C ~ 125°C (TJ) | Chassis Mount | E3 |
|
|
MIXA10W1200TMLIGBT MODULE 1200V 17A 65W E1 |
4,812 | - |
|
Datasheet | - | E1 | Box | Active | PT | Three Phase Inverter | 1200 V | 17 A | 65 W | 2.1V @ 15V, 9A | 150 µA | - | Standard | Yes | -40°C ~ 125°C (TJ) | Chassis Mount | E1 |
|
|
MIXA10WB1200TMLIGBT MODULE 1200V 17A 63W E1 |
8,182 | - |
|
Datasheet | - | E1 | Box | Active | PT | Three Phase Inverter with Brake | 1200 V | 17 A | 63 W | 2.1V @ 15V, 9A | 100 µA | - | Three Phase Bridge Rectifier | Yes | -40°C ~ 125°C (TJ) | Chassis Mount | E1 |
|
|
MIXA151W1200EHIGBT MODULE 1200V 220A 695W |
8,477 | - |
|
Datasheet | - | - | Box | Active | PT | Three Phase Inverter | 1200 V | 220 A | 695 W | 2.1V @ 15V, 150A | 500 µA | - | Standard | No | -40°C ~ 125°C (TJ) | - | - |
|
|
MIXA20WB1200TMLIGBT MOD 1200V 28A MINIPACK2 |
7,837 | - |
|
Datasheet | - | MiniPack2 | Box | Active | PT | Three Phase Inverter with Brake | 1200 V | 28 A | 100 W | 2.1V @ 15V, 16A | 100 µA | - | Three Phase Bridge Rectifier | Yes | -40°C ~ 125°C (TJ) | Chassis Mount | MiniPack2 |
|
|
MIXA100PF1200TMHIGBT MOD 1200V 155A MINIPACK2 |
5,100 | - |
|
Datasheet | - | MiniPack2 | Box | Obsolete | - | Half Bridge | 1200 V | 155 A | 500 W | 2.1V @ 15V, 100A | 300 µA | - | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | MiniPack2 |
