Analog Switches - Special Purpose
Browse available Analog Switches - Special Purpose part numbers with manufacturer references, stock information, pricing, datasheets and key specifications. Use the table below to compare options for your project.
For BOM, shortage or hard-to-find requirements, send your part number and quantity to Winsun (HK) Electronics for availability, lead-time and quotation support.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Applications | Multiplexer/Demultiplexer Circuit | Switch Circuit | Number of Channels | On-State Resistance (Max) | Voltage - Supply, Single (V+) | Voltage - Supply, Dual (V±) | -3db Bandwidth | Features | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FSA2567UMXIC SWITCH 4PDT 16UMLP |
30,395 | - |
|
Datasheet | - | 16-UFQFN | Tape & Reel (TR) | Active | Telecommunications | - | 4PDT | 1 | 10Ohm | 1.65V ~ 4.3V | - | 475MHz | Break-Before-Make | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-UMLP (1.8x2.6) |
|
TS3USB30RSWRIC USB SWITCH DUAL 1X2 10UQFN |
15,782 | - |
|
Datasheet | - | 10-UFQFN | Tape & Reel (TR) | Active | USB | - | DPDT | 1 | 10Ohm | 3V ~ 4.3V | - | 955MHz | Bi-Directional, USB 2.0 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 10-UQFN (1.8x1.4) |
|
TS3L501ERUARIC LAN MUX/DMUX 16B TO 8B 42WQFN |
4,732 | - |
|
Datasheet | - | 42-WFQFN Exposed Pad | Tape & Reel (TR) | Active | Networking | 2:1 | SPDT | 11 | 8Ohm | 3V ~ 3.6V | - | 600MHz | 10/100,1000 Base-T, LVDS, LVPECL | -40°C ~ 85°C (TA) | - | - | Surface Mount | 42-WQFN (3.5x9) |
|
CBTU02044HEJSWITCH 1-2 PCIE GEN4 HUQFN16 |
35,637 | - |
|
Datasheet | - | 16-UFQFN Exposed Pad | Tape & Reel (TR) | Active | PCIe | 1:2 | SPDT | 2 | 14Ohm | 1.62V ~ 3.63V | - | 17GHz | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-HUQFN (1.6x2.4) |
|
CBTL02043ABQ,115IC MUX/DEMUX 2:1 PCI 20DHVQFN |
11,676 | - |
|
Datasheet | - | 20-VFQFN Exposed Pad | Tape & Reel (TR) | Active | DisplayPort, PCIe, USB | 2:1 | - | 2 | 6Ohm (Typ) | 3V ~ 3.6V | - | 10GHz | Bi-Directional, SATA | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-DHVQFN (4.5x2.5) |
|
|
FSUSB74UMXIC USB MUX/SWITCH 16UMLP |
11,150 | - |
|
Datasheet | - | 16-UFQFN | Tape & Reel (TR) | Active | USB | 4:1 | - | 1 | 9Ohm | 2.5V ~ 4.4V | - | - | Break-Before-Make, USB 2.0 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-UMLP (1.8x2.6) |
|
PI3USB102EZLEXIC USB 2.0 SWITCH 10TQFN |
23,773 | - |
|
Datasheet | - | 10-WFQFN | Tape & Reel (TR) | Active | USB | 2:1 | - | 1 | 4Ohm (Typ) | 3V ~ 5.5V | - | 1GHz | Bi-Directional, USB 2.0 | - | - | - | Surface Mount | 10-TQFN (1.3x1.6) |
|
|
CBTL02042ABQ,115IC MUX/DEMUX 2:1 PCI 20DHVQFN |
10,414 | - |
|
Datasheet | - | 20-VFQFN Exposed Pad | Tape & Reel (TR) | Active | DisplayPort, PCIe, USB | 2:1 | - | 2 | 6Ohm (Typ) | 3V ~ 3.6V | - | 7GHz | Bi-Directional, SATA | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-DHVQFN (4.5x2.5) |
|
PI3WVR646GEEXANALOG SWITCH 3V-5V U-WLB2424-36 |
8,515 | - |
|
Datasheet | - | 36-UFBGA, WLCSP | Tape & Reel (TR) | Active | Telecommunications | 2:1 | SPDT | 10 | 6Ohm (Typ) | 1.5V ~ 5V | - | 4.5GHz | Differential Compatibility | -40°C ~ 85°C (TA) | - | - | Surface Mount | 36-CSP (2.44x2.44) |
|
FSUSB43L10XIC USB MUX/SWITCH 10MICROPAK |
7,982 | - |
|
Datasheet | - | 10-UFQFN Exposed Pad | Tape & Reel (TR) | Active | USB | - | DPDT | 1 | 6.5Ohm | 3V ~ 4.3V | - | 720MHz | Break-Before-Make, USB 2.0 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 10-MicroPak™ |
|
PI3WVR648GEAEXMIPI SWITCH U-WLB2424-36 |
107 | - |
|
Datasheet | - | 36-UFBGA, WLCSP | Tape & Reel (TR) | Active | Telecommunications | 2:1 | SPDT | 10 | - | 1.5V ~ 5V | - | 6GHz | - | - | - | - | Surface Mount | 36-WLCSP (2.44x2.44) |
|
FSA553UCXIC AUDIO SWITCH SPST DUAL WLCSP |
11,453 | - |
|
Datasheet | - | 9-UFBGA, WLCSP | Tape & Reel (TR) | Active | Audio | 1:1 | SPST | 2 | 800mOhm | 1.5V ~ 3V | - | 200MHz | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | 9-WLCSP (1.22x1.22) |
|
TS3DDR4000ZBARIC DDR SWITCH/MUX 48NFBGA |
3,049 | - |
|
Datasheet | - | 48-TFBGA | Tape & Reel (TR) | Active | Memory | 2:1 | - | 1 | 11.2Ohm | 2.375V ~ 3.6V | - | 5.6GHz | DDR2, DDR3, DDR4 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 48-NFBGA (8x3) |
|
FSA660TMXIC SWITCH 2:1 MIPI C-PHY 18TMLP |
4,135 | - |
|
Datasheet | - | 18-XFQFN Exposed Pad | Tape & Reel (TR) | Active | MIPI | 2:1 | SPDT | 1 | 8Ohm | 1.5V ~ 5V | - | 5GHz | Break-Before-Make | -40°C ~ 85°C (TA) | - | - | Surface Mount | 18-TMLP (2x2.8) |
|
PI3USB302-AZBEXIC MUX/DEMUX USB 3.0 20TQFN |
3,300 | - |
|
Datasheet | - | 20-VFQFN Exposed Pad | Tape & Reel (TR) | Active | USB | 2:1 | - | 2 | - | 3V ~ 3.6V | - | - | Bi-Directional, USB 3.0 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-QFN (2.5x4.5) |
|
FSA636UCXULTRA SMALL, LOW POWER, 4-DATA L |
132 | - |
|
Datasheet | - | 36-XFBGA, WLCSP | Tape & Reel (TR) | Active | DisplayPort, PCIe, Telecommunications, USB | 2:1 | SPDT | 10 | 9Ohm | 1.5V ~ 5V | - | 4GHz | Break-Before-Make | -40°C ~ 85°C (TA) | - | - | Surface Mount | 36-WLCSP (2.06x2.06) |
|
PI3DBS16212XUAEXPCIE SWITCH X2-QFN2020-18 |
12,291 | - |
|
Datasheet | - | 18-XFQFN Exposed Pad | Tape & Reel (TR) | Active | USB | 2:1 | SPDT | 2 | - | 3.3V | - | 13GHz | Bi-Directional, USB 3.0, USB 3.1 | -40°C ~ 85°C | - | - | Surface Mount | 18-X2QFN (2x2) |
|
PI3DBS16212ZBBEXPCIE SWITCH V-QFN2545-20 T&R 3.5 |
61,110 | - |
|
Datasheet | - | 20-VFQFN Exposed Pad | Tape & Reel (TR) | Active | USB | 2:1 | SPDT | 2 | - | 3.3V | - | 13GHz | Bi-Directional, USB 3.0, USB 3.1 | -40°C ~ 85°C | - | - | Surface Mount | 20-TQFN (2.5x4.5) |
|
PI3PCIE3412AZHEXPCI SWITCH 2:1 4 CHAN 42TQFN |
24,341 | - |
|
Datasheet | PCI Express® (PCIe) | 42-VFQFN Exposed Pad | Tape & Reel (TR) | Active | PCI Express® | 2:1 | - | 4 | 5Ohm (Typ) | 3V ~ 3.6V | - | 8.2GHz | Bi-Directional, SATA, USB 3.0 | -40°C ~ 85°C | - | - | Surface Mount | 42-TQFN (9x3.5) |
|
PI3DBS16213ZLEXPCIE SWITCH W-QFN2545-30 |
6,260 | - |
|
Datasheet | - | 30-WFQFN Exposed Pad | Tape & Reel (TR) | Active | USB | 3:1 | SP3T | 2 | - | 3.3V | - | 12GHz | Bi-Directional, USB 3.0, USB 3.1 | -40°C ~ 85°C | - | - | Surface Mount | 30-TQFN (2.5x4.5) |
Analog Switches - Special Purpose FAQ
Common questions about selecting, comparing and sourcing Analog Switches - Special Purpose components through Winsun (HK) Electronics.
What should I check when selecting Analog Switches - Special Purpose components?
Compare the manufacturer part number, electrical specifications, package, operating conditions and application requirements. The product datasheet should be used to confirm technical suitability.
Can Winsun help source specific Analog Switches - Special Purpose part numbers?
Yes. Send the exact part number, manufacturer and required quantity. Winsun (HK) Electronics can assist with availability checks, quotation support and sourcing options based on your requirement.
Do you support shortage, obsolete or hard-to-find Analog Switches - Special Purpose parts?
Yes. Our sourcing team can review shortage and obsolete-part requirements and help check available supply channels or possible alternatives when appropriate.
How do I request a quote for Analog Switches - Special Purpose components?
Submit an RFQ with the part number, manufacturer, quantity and target delivery requirement. Our sales team will review your request and follow up with current sourcing information.
