Gates and Inverters
Browse available Gates and Inverters part numbers with manufacturer references, stock information, pricing, datasheets and key specifications. Use the table below to compare options for your project.
For BOM, shortage or hard-to-find requirements, send your part number and quantity to Winsun (HK) Electronics for availability, lead-time and quotation support.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Logic Type | Number of Circuits | Number of Inputs | Features | Voltage - Supply | Current - Quiescent (Max) | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High | Max Propagation Delay @ V, Max CL | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHC32NSIC GATE OR 4CH 2-INP 14SO |
2,594 | - |
|
Datasheet | 74AHC | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | OR Gate | 4 | 2 | - | 2V ~ 5.5V | 2 µA | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V | 7.5ns @ 5V, 50pF | -40°C ~ 125°C | - | - | Surface Mount | 14-SO |
|
SN74LVC08ANSIC GATE AND 4CH 2-INP 14SO |
3,955 | - |
|
Datasheet | 74LVC | 14-SOIC (0.209", 5.30mm Width) | Tube | Active | AND Gate | 4 | 2 | - | 1.65V ~ 3.6V | 10 µA | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V | 3.9ns @ 3.3V, 50pF | -40°C ~ 125°C | - | - | Surface Mount | 14-SO |
|
SN74LS38DBIC GATE NAND 4CH 2-INP 14SSOP |
2,993 | - |
|
Datasheet | 74LS | 14-SSOP (0.209", 5.30mm Width) | Bulk | Obsolete | NAND Gate | 4 | 2 | Open Collector | 4.75V ~ 5.25V | 12 mA | 250µA, 24mA | 0.8V | 2V | 32ns @ 5V, 45pF | 0°C ~ 70°C | - | - | Surface Mount | 14-SSOP |
|
SN74LS38NSIC GATE NAND 4CH 2-INP 14SO |
2,100 | - |
|
Datasheet | 74LS | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | NAND Gate | 4 | 2 | Open Collector | 4.75V ~ 5.25V | 12 mA | 250µA, 24mA | 0.8V | 2V | 32ns @ 5V, 45pF | 0°C ~ 70°C | - | - | Surface Mount | 14-SO |
|
SN74HC14APWIC INVERTER 6CH 6-INP 14TSSOP |
4,523 | - |
|
Datasheet | 74HC | 14-TSSOP (0.173", 4.40mm Width) | Bulk | Obsolete | Inverter | 6 | 6 | Schmitt Trigger | 2V ~ 6V | 2 µA | 5.2mA, 5.2mA | 1V ~ 3.2V | 1.5V ~ 4.2V | 19ns @ 6V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-TSSOP |
|
|
SN74F20NSIC GATE NAND 2CH 4-INP 14SO |
3,316 | - |
|
Datasheet | 74F | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | NAND Gate | 2 | 4 | - | 4.5V ~ 5.5V | 5.1 mA | 1mA, 20mA | 0.8V | 2V | 6ns @ 5V, 50pF | 0°C ~ 70°C | - | - | Surface Mount | 14-SO |
|
SN74LVC08ADBIC GATE AND 4CH 2-INP 14SSOP |
2,011 | - |
|
Datasheet | 74LVC | 14-SSOP (0.209", 5.30mm Width) | Bulk | Active | AND Gate | 4 | 2 | - | 1.65V ~ 3.6V | 10 µA | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V | 3.9ns @ 3.3V, 50pF | -40°C ~ 125°C | - | - | Surface Mount | 14-SSOP |
|
|
SN74AC32NSIC GATE OR 4CH 2-INP 14SO |
3,106 | - |
|
Datasheet | 74AC | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | OR Gate | 4 | 2 | - | 2V ~ 6V | 2 µA | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V | 7.5ns @ 5V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-SO |
|
SN74LS30NSIC GATE NAND 1CH 8-INP 14SO |
4,500 | - |
|
Datasheet | 74LS | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | NAND Gate | 1 | 8 | - | 4.75V ~ 5.25V | 1.1 mA | 400µA, 8mA | 0.8V | 2V | 6.5ns @ 5V, 50pF | 0°C ~ 70°C | - | - | Surface Mount | 14-SO |
|
SN74HCU04APWIC INVERTER 6CH 6-INP 14TSSOP |
4,182 | - |
|
Datasheet | 74HCU | 14-TSSOP (0.173", 4.40mm Width) | Bulk | Obsolete | Inverter | 6 | 6 | - | 2V ~ 6V | 2 µA | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.7V ~ 4.8V | 10ns @ 6V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-TSSOP |
|
SN74LS32NSIC GATE OR 4CH 2-INP 14SO |
2,410 | - |
|
Datasheet | 74LS | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | OR Gate | 4 | 2 | - | 4.75V ~ 5.25V | 9.8 mA | 400µA, 8mA | 0.8V | 2V | 22ns @ 5V, 15pF | 0°C ~ 70°C | - | - | Surface Mount | 14-SO |
|
|
CD4002BNSIC GATE NOR 2CH 4-INP 14SO |
2,507 | - |
|
Datasheet | - | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | NOR Gate | 2 | 4 | - | 3V ~ 18V | 5 µA | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V | 90ns @ 15V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 14-SO |
|
|
SN74HC20ANIC GATE NAND 2CH 4-INP 14DIP |
4,302 | - |
|
Datasheet | 74HC | 14-DIP (0.300", 7.62mm) | Bulk | Active | NAND Gate | 2 | 4 | - | 2V ~ 6V | 2 µA | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V | 19ns @ 6V, 50pF | -40°C ~ 85°C | - | - | Through Hole | 14-PDIP |
|
|
SN74HC11NSIC GATE AND 3CH 3-INP 14SO |
4,990 | - |
|
Datasheet | 74HC | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | AND Gate | 3 | 3 | - | 2V ~ 6V | 2 µA | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V | 17ns @ 6V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-SO |
|
|
CD4001BNSIC GATE NOR 4CH 2-INP 14SO |
3,045 | - |
|
Datasheet | - | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | NOR Gate | 4 | 2 | - | 3V ~ 18V | 5 µA | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V | 90ns @ 15V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 14-SO |
|
SN74AHC14PWRG3-JIC INVERTER 6CH 6-INP 14TSSOP |
3,254 | - |
|
Datasheet | 74AHC | 14-TSSOP (0.173", 4.40mm Width) | Bulk | Obsolete | Inverter | 6 | 6 | Schmitt Trigger | 2V ~ 5.5V | 1 µA | 8mA, 8mA | 1.9V ~ 3.35V | 2.2V ~ 3.85V | 10.6ns @ 5V, 50pF | -40°C ~ 125°C | - | - | Surface Mount | 14-TSSOP |
|
|
SN74LV14ANS-PIC INVERT SCHMITT 6CH 6-INP 14SO |
2,137 | - |
|
Datasheet | 74LV | 14-SOIC (0.209", 5.30mm Width) | Bulk | Active | Inverter | 6 | 6 | Schmitt Trigger | 2V ~ 5.5V | 20 µA | 12mA, 12mA | 0.75V ~ 1.5V | 1.75V ~ 3.5V | 10.6ns @ 5V, 50pF | -40°C ~ 125°C | - | - | Surface Mount | 14-SO |
|
|
SN74LVC04AQDRCTIC INVERTER 6CH 6-INP 14SOIC |
3,923 | - |
|
Datasheet | 74LVC | 14-SOIC (0.154", 3.90mm Width) | Bulk | Active | Inverter | 6 | 6 | - | 1.65V ~ 3.6V | 1 µA | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V | 4.3ns @ 3.3V, 50pF | -40°C ~ 125°C | - | - | Surface Mount | 14-SOIC |
|
|
SN74LS03NSIC GATE NAND 4CH 2-INP 14SO |
4,206 | - |
|
Datasheet | 74LS | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | NAND Gate | 4 | 2 | Open Collector | 4.75V ~ 5.25V | 4.4 mA | 100µA, 8mA | 0.8V | 2V | 32ns @ 5V, 15pF | 0°C ~ 70°C | - | - | Surface Mount | 14-SO |
|
|
CD74HC132E-NGIC GATE NAND 4CH 2-INP 14DIP |
4,260 | - |
|
Datasheet | 74HC | 14-DIP (0.300", 7.62mm) | Bulk | Obsolete | NAND Gate | 4 | 2 | Schmitt Trigger | 2V ~ 6V | 2 µA | 5.2mA, 5.2mA | 1V ~ 3V | 1.5V ~ 4.2V | 21ns @ 6V, 50pF | -55°C ~ 125°C | - | - | Through Hole | 14-PDIP |
