Power Transformers
Use the filters and product table below to compare Power Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PWDP13006PWR XFMR LAMINATED CHAS MT |
3,383 | - |
|
Datasheet | PWDAHL | Box | Obsolete | Laminated Core | 120V, 240V | 800V, 120V, 6.3V | 500mA | Dual | Triple | Yes | - | Chassis Mount | Wire Leads | 133.35mm L x 132.21mm W | 111.13mm | - | - |
|
265Z5PWR XFMR LAMINATED 450VA CHAS MT |
2,031 | - |
|
Datasheet | - | Case | Active | Laminated Core | 115V | 5V | 90A | Dual | Single, Multiple Taps | Yes | 450VA | Chassis Mount | Solder, Quick Connect | - | 107.95mm | - | - |
|
PWDP13104PWR XFMR C-CORE 2300/2700V/3100V |
1,800 | - |
|
Datasheet | PWDAHL | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
PWDP13166PWR XFMR |
2,326 | - |
|
Datasheet | * | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
PWDP13209PWR XFMR |
4,231 | - |
|
Datasheet | * | Bulk | Obsolete | - | 120V, 240V | 2400V | - | - | - | - | - | - | - | - | - | - | - |
|
|
PWDP13262XFRMR EICO 720 PWER 90W |
1,422 | - |
|
Datasheet | - | Case | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
PWDP13023PWR XFMR CHAS MT |
1,232 | - |
|
Datasheet | PWDAHL | Case | Active | - | 117V | 427V, 230V, 90V, 19.2V | 300mA, 300mA, 140mA, 6A | Single | Four | Yes | - | Chassis Mount | Wire Leads | 107.95mm L x 95.25mm W | 114.30mm | - | - |
|
|
PWDI13036PWR XFMR CHAS MT |
1,684 | - |
|
Datasheet | PWDAHL | Case | Active | - | - | - | - | Single | - | Yes | - | Chassis Mount | Wire Leads | 129.54mm L x 111.13mm W | 134.62mm | - | - |
|
|
PWDM13220PWR XFMR CHAS MT |
3,724 | - |
|
Datasheet | PWDAHL | Case | Obsolete | - | 785V | - | 250mA | Single | Single | No | - | Chassis Mount | Wire Leads | - | - | - | - |
|
|
185E230-BULKTools/Equipment/Hardware |
3,770 | - |
|
Datasheet | 185 | Bulk | Active | - | 115V, 230V | Parallel 115V, Series 230V | Parallel 700mA, Series 350mA | Dual | Dual | No | 80VA | Chassis Mount | Solder, Quick Connect | 66.29mm L x 63.50mm W | 76.20mm | 4000Vrms | - |
Power Transformers FAQ
Common questions about filtering, comparing and sourcing Power Transformers components.
How can I narrow the Power Transformers selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Power Transformers part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
