Diode Arrays
Use the filters and product table below to compare Diode Arrays components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Diode Configuration | Technology | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) (per Diode) | Voltage - Forward (Vf) (Max) @ If | Speed | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Operating Temperature - Junction | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DD200S33K2CC1NOSA1DIODE MOD GP 3300V 200A AIHV73-3 |
9,021 | - |
|
Datasheet | - | Module | Bulk | Obsolete | 1 Pair Series Connection | Standard | 3300 V | 200A (DC) | 3.5 V @ 200 A | Standard Recovery >500ns, > 200mA (Io) | - | - | -40°C ~ 125°C | - | - | Chassis Mount | A-IHV73-3 |
|
BAV70E6767DIODE ARRAY GEN PURP 80V 200MA |
96,000 | - |
|
Datasheet | - | TO-236-3, SC-59, SOT-23-3 | Bulk | Active | 1 Pair Common Cathode | Standard | 80 V | 200mA (DC) | 1.25 V @ 150 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 150 nA @ 70 V | 150°C | Automotive | AEC-Q101 | Surface Mount | - |
|
DD100N16SHPSA1DIODE MOD GP 1600V 130A MOD |
24 | - |
|
Datasheet | - | Module | Tray | Active | 1 Pair Series Connection | Standard | 1600 V | 130A | - | - | - | - | - | - | - | Chassis Mount | Module |
|
DD98N22KHPSA1DIODE MODULE GP 2200V 98A MODULE |
5 | - |
|
Datasheet | - | Module | Tray | Active | 1 Pair Series Connection | Standard | 2200 V | 98A | 1.53 V @ 300 A | Standard Recovery >500ns, > 200mA (Io) | - | 25 mA @ 2200 V | -40°C ~ 150°C | - | - | Chassis Mount | Module |
|
DZ800S17K3HOSA1DIODE MODULE GP 1700V AG62MM-2 |
22 | - |
|
Datasheet | - | Module | Tray | Active | - | Standard | 1700 V | - | 2.2 V @ 800 A | Standard Recovery >500ns, > 200mA (Io) | - | - | -40°C ~ 125°C | - | - | Chassis Mount | AG-62MM-2 |
|
DD260N16KHPSA1DIODE MOD GP 1600V 260A MOD |
3 | - |
|
Datasheet | - | Module | Tray | Active | 1 Pair Series Connection | Standard | 1600 V | 260A | 1.32 V @ 800 A | Standard Recovery >500ns, > 200mA (Io) | - | 30 mA @ 1600 V | -40°C ~ 150°C | - | - | Chassis Mount | Module |
|
DD1000S33HE3BPSA1DIODE MODULE GP 3300V AGIHVB1303 |
2 | - |
|
Datasheet | - | Module | Bulk | Active | 2 Independent | Standard | 3300 V | - | 3.85 V @ 1000 A | Standard Recovery >500ns, > 200mA (Io) | - | - | -40°C ~ 150°C | - | - | Chassis Mount | AG-IHVB130-3 |
|
|
DD600S65K3NOSA1DIODE MODULE GP 6500V AIHV130-6 |
2 | - |
|
Datasheet | - | Module | Tray | Active | 2 Independent | Standard | 6500 V | - | 3.5 V @ 600 A | Standard Recovery >500ns, > 200mA (Io) | - | - | -50°C ~ 125°C | - | - | Chassis Mount | A-IHV130-6 |
|
BAS7006WH6327XTSA1DIODE ARR SCHOTT 70V 70MA SOT323 |
240 | - |
|
Datasheet | - | SC-70, SOT-323 | Tape & Reel (TR) | Active | 1 Pair Common Anode | Schottky | 70 V | 70mA (DC) | 1 V @ 15 mA | Small Signal =< 200mA (Io), Any Speed | 100 ps | 100 nA @ 50 V | 150°C (Max) | - | - | Surface Mount | PG-SOT323 |
|
IDW80C65D2XKSA1DIODE ARRAY GP 650V 40A TO247-3 |
94 | - |
|
Datasheet | Rapid 2 | TO-247-3 | Tube | Active | 1 Pair Common Cathode | Standard | 650 V | 40A | 2.2 V @ 40 A | Fast Recovery =< 500ns, > 200mA (Io) | 36 ns | 40 µA @ 650 V | -40°C ~ 175°C | - | - | Through Hole | PG-TO247-3 |
