Single Diodes
Use the filters and product table below to compare Single Diodes components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Voltage - Forward (Vf) (Max) @ If | Speed | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Capacitance @ Vr, F | Grade | Qualification | Mounting Type | Supplier Device Package | Operating Temperature - Junction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CURM105-GDIODE GP 600V 1A MINI SMA/SOD123 |
6,552 | - |
|
Datasheet | - | SOD-123T | Tape & Reel (TR) | Obsolete | Standard | 600 V | 1A | 1.7 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 5 µA @ 600 V | 20pF @ 4V, 1MHz | - | - | Surface Mount | Mini SMA/SOD-123 | -55°C ~ 150°C |
|
CURMT102-HFDIODE GEN PURP 100V 1A SOD123H |
8,281 | - |
|
Datasheet | - | SOD-123H | Tape & Reel (TR) | Obsolete | Standard | 100 V | 1A | 1 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 5 µA @ 100 V | 70pF @ 4V, 1MHz | - | - | Surface Mount | SOD-123H | -55°C ~ 150°C |
|
|
CURMT105-HFDIODE GEN PURP 600V 1A SOD123H |
3,748 | - |
|
Datasheet | - | SOD-123H | Tape & Reel (TR) | Obsolete | Standard | 600 V | 1A | 1.7 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 5 µA @ 600 V | 70pF @ 4V, 1MHz | - | - | Surface Mount | SOD-123H | -55°C ~ 150°C |
|
CDBZ61045-HFDIODE SCHOTTKY 45V 10A TO252 |
6,692 | - |
|
Datasheet | - | Z6 | Tape & Reel (TR) | Obsolete | Schottky | 45 V | 10A | 550 mV @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 45 V | - | - | - | Surface Mount | TO-252 (Z6) | -55°C ~ 150°C |
|
UF4001-GDIODE GEN PURP 50V 1A DO41 |
4,102 | - |
|
Datasheet | - | DO-204AL, DO-41, Axial | Tape & Box (TB) | Obsolete | Standard | 50 V | 1A | 1 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 5 µA @ 50 V | 20pF @ 4V, 1MHz | - | - | Through Hole | DO-41 | -55°C ~ 150°C |
|
|
UF4002-GDIODE GEN PURP 100V 1A DO41 |
3,726 | - |
|
Datasheet | - | DO-204AL, DO-41, Axial | Tape & Box (TB) | Obsolete | Standard | 100 V | 1A | 1 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 5 µA @ 100 V | 20pF @ 4V, 1MHz | - | - | Through Hole | DO-41 | -55°C ~ 150°C |
|
|
UF4004-GDIODE GEN PURP 300V 1A DO41 |
4,327 | - |
|
Datasheet | - | DO-204AL, DO-41, Axial | Tape & Box (TB) | Obsolete | Standard | 300 V | 1A | 1.3 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 5 µA @ 300 V | 20pF @ 4V, 1MHz | - | - | Through Hole | DO-41 | -55°C ~ 150°C |
|
|
UF4006-GDIODE GEN PURP 600V 1A DO41 |
8,458 | - |
|
Datasheet | - | DO-204AL, DO-41, Axial | Tape & Box (TB) | Obsolete | Standard | 600 V | 1A | 1.7 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 5 µA @ 600 V | 10pF @ 4V, 1MHz | - | - | Through Hole | DO-41 | -55°C ~ 150°C |
|
|
UF4007-GDIODE GEN PURP 800V 1A DO41 |
3,310 | - |
|
Datasheet | - | DO-204AL, DO-41, Axial | Tape & Box (TB) | Obsolete | Standard | 800 V | 1A | 1.7 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 5 µA @ 800 V | 10pF @ 4V, 1MHz | - | - | Through Hole | DO-41 | -55°C ~ 150°C |
|
CDBM140LR-HFDIODE SCHOTTKY 40V 1A SOD123F |
9,473 | - |
|
Datasheet | - | SOD-123F | Tape & Reel (TR) | Obsolete | Schottky | 40 V | 1A | 450 mV @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 200 µA @ 30 V | 200pF @ 4V, 1MHz | - | - | Surface Mount | SOD-123F | -50°C ~ 125°C |
Single Diodes FAQ
Common questions about filtering, comparing and sourcing Single Diodes components.
How can I narrow the Single Diodes selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Single Diodes part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
