RF Directional Coupler
Browse available RF Directional Coupler part numbers with manufacturer references, stock information, pricing, datasheets and key specifications. Use the table below to compare options for your project.
For BOM, shortage or hard-to-find requirements, send your part number and quantity to Winsun (HK) Electronics for availability, lead-time and quotation support.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Coupler Type | Frequency | Coupling Factor | Applications | Insertion Loss | Power - Max | Isolation | Return Loss | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0870CF16A1810001EIC |
1,402 | - |
|
Datasheet | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - |
|
|
1472CH15A050001EIC |
3,411 | - |
|
Datasheet | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - |
|
|
0836CP07A0025001TIC |
3,847 | - |
|
Datasheet | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - |
|
PE2CP102990D PCB HYB CPL 100-500MHZ 150W |
4,876 | - |
|
Datasheet | - | Bag | Active | Standard | 100MHz ~ 500MHz | - | General Purpose | 0.5dB | 150W | 16dB | - | Module |
|
PE2CP105090DEG PCB HYB CPL 1-2GHZ 400W |
2,043 | - |
|
Datasheet | - | Bag | Active | Standard | 1GHz ~ 2GHz | - | General Purpose | 0.2dB | 400W | 20dB | - | Module |
|
PE2CP104690D PCB HYB CPL 0.8-2.5GHZ 200W |
2,588 | - |
|
Datasheet | - | Bag | Active | Standard | 800MHz ~ 2.5GHz | - | General Purpose | 0.5dB | 200W | 18dB | - | Module |
|
|
PE2CP1061Low PIM Directional 10 dB N Coup |
1,811 | - |
|
Datasheet | - | Retail Package | Active | Standard | 698MHz ~ 2.7GHz | 10 ± 1.2dB | 4G, PCS | 0.25dB | 200W | - | - | Module |
|
|
BC0560-10-SFDirectional Coupler 0.5 to 6 GHz |
4,293 | - |
|
Datasheet | - | Case | Active | Standard | 500MHz ~ 6GHz | 10dB ± 1dB | General Purpose | 1.2dB | 50W | - | - | - |
|
|
BC0560-20-SFDirectional Coupler (0.5 to 6 GH |
3,030 | - |
|
Datasheet | - | Case | Active | Standard | 500MHz ~ 6GHz | 20 ± 1dB | General Purpose | 0.7dB | 30W | 15dB | - | - |
|
|
BC0560-30-SFDirectional Coupler (0.5 to 6 GH |
1,271 | - |
|
Datasheet | - | Case | Active | Standard | 500MHz ~ 6GHz | 30 ± 1dB | General Purpose | 0.7dB | 30W | 15dB | - | - |
|
PE2CP105390DEG PCB HYB CPL 1-3GHZ 450W |
4,265 | - |
|
Datasheet | - | Bag | Active | Standard | 1GHz ~ 3GHz | - | General Purpose | 0.25dB | 450W | 16dB | - | Module |
|
|
PE2CP1024-6Directional 6 dB SMA Coupler Fro |
4,512 | - |
|
Datasheet | - | Retail Package | Active | Standard | 800MHz ~ 2.5GHz | 6 ± 1dB | CDMA, GSM, LTE | 0.5dB | 50W | - | - | Module |
|
PE2CP104390D PCB HYB CPL 0.5-3GHZ 125W |
4,767 | - |
|
Datasheet | - | Bag | Active | Standard | 500MHz ~ 3GHz | - | General Purpose | 0.6dB | 125W | 18dB | - | Module |
|
|
PE2CP1074Low PIM Directional 30 dB 7/16 D |
1,301 | - |
|
Datasheet | - | Retail Package | Active | Standard | 380MHz ~ 4GHz | 30 ± 1.5dB | 4G, PCS | 0.25dB | 200W | - | - | - |
|
|
PE2220-10Dual Directional 10 dB SMA Coupl |
3,202 | - |
|
Datasheet | - | Retail Package | Active | Standard | 2.6GHz ~ 5.2GHz | 10 ± 1.25dB | General Purpose | 1.5dB | 10W | - | - | Module |
|
|
PEWCP1042WR-42 Waveguide 50 dB Crossguide |
3,110 | - |
|
Datasheet | - | Retail Package | Active | Standard | 18GHz ~ 26.5GHz | 50dB | General Purpose | 0.1dB | - | - | - | - |
|
|
PEWCP1050WR-62 Waveguide 50 dB Crossguide |
4,943 | - |
|
Datasheet | - | Retail Package | Active | Standard | 12.4GHz ~ 18GHz | 50dB | General Purpose | 0.1dB | - | - | - | - |
|
PE2CP104190D PCB HYB CPL 0.5-2.5GHZ 200W |
2,386 | - |
|
Datasheet | - | Bag | Active | Standard | 500MHz ~ 2.5GHz | - | General Purpose | 0.5dB | 200W | 17dB | - | Module |
|
PE2CP114090DEG HYB CPL 500MHZ-1GHZ 50W |
4,101 | - |
|
Datasheet | - | Bag | Active | Standard | 500MHz ~ 1GHz | 3dB | General Purpose | 0.2dB | 50W | 22dB | - | Module |
|
|
PE2242-30Directional 30 dB SMA Coupler Fr |
4,349 | - |
|
Datasheet | - | Retail Package | Active | Standard | 500MHz ~ 3GHz | 30 ± 1.5dB | General Purpose | 0.45dB | 50W | - | - | Module |
RF Directional Coupler FAQ
Common questions about selecting, comparing and sourcing RF Directional Coupler components through Winsun (HK) Electronics.
What should I check when selecting RF Directional Coupler components?
Compare the manufacturer part number, electrical specifications, package, operating conditions and application requirements. The product datasheet should be used to confirm technical suitability.
Can Winsun help source specific RF Directional Coupler part numbers?
Yes. Send the exact part number, manufacturer and required quantity. Winsun (HK) Electronics can assist with availability checks, quotation support and sourcing options based on your requirement.
Do you support shortage, obsolete or hard-to-find RF Directional Coupler parts?
Yes. Our sourcing team can review shortage and obsolete-part requirements and help check available supply channels or possible alternatives when appropriate.
How do I request a quote for RF Directional Coupler components?
Submit an RFQ with the part number, manufacturer, quantity and target delivery requirement. Our sales team will review your request and follow up with current sourcing information.
