Crystals
Use the filters and product table below to compare Crystals components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Frequency | Frequency Stability | Frequency Tolerance | Load Capacitance | ESR (Equivalent Series Resistance) | Operating Mode | Operating Temperature | Ratings | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0153G2-16.000F12DTLKCRYSTAL 16MHZ 12PF SMD |
85,160 | - |
|
Datasheet | 0153G2 | 2-SMD, No Lead | Tape & Reel (TR) | Active | MHz Crystal | 16 MHz | ±25ppm | ±20ppm | 12pF | 60 kOhms | Fundamental | -40°C ~ 85°C | - | Surface Mount | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.051" (1.30mm) |
|
|
0122M4-25.000F12AZLAK2520 25MHz 12pF +/-20ppm -55-125 |
78,109 | - |
|
Datasheet | 0122M4 | 4-SMD, No Lead | Tape & Reel (TR) | Active | MHz Crystal | 25 MHz | ±100ppm | ±20ppm | 12pF | 50 Ohms | Fundamental | -55°C ~ 125°C | - | Surface Mount | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.024" (0.60mm) |
|
XC11M4-26.000-F09NJDTKCRYSTAL 26MHz 9PF SMD |
70,400 | - |
|
Datasheet | XC11M4 | 4-SMD, No Lead | Tape & Box (TB) | Active | MHz Crystal | 26 MHz | ±10ppm | ±20ppm | 9pF | 100 Ohms | Fundamental | -40°C ~ 85°C | - | Surface Mount | - | 0.063" L x 0.047" W (1.60mm x 1.20mm) | 0.018" (0.45mm) |
|
|
XC11M4-24.000-F12NLDTKCRYSTAL 24MHZ 12PF SMD |
70,400 | - |
|
Datasheet | XC11M4 | 4-SMD, No Lead | Tape & Reel (TR) | Active | MHz Crystal | 24 MHz | ±20ppm | ±10ppm | 12pF | 120 Ohms | Fundamental | -40°C ~ 85°C | - | Surface Mount | - | 0.063" L x 0.047" W (1.60mm x 1.20mm) | 0.018" (0.45mm) |
|
|
0122M4-14.31818F20DTNJKCRYSTAL 14.31818MHZ 20PF SMD |
57,100 | - |
|
Datasheet | 0122M4 | 4-SMD, No Lead | Tape & Reel (TR) | Active | MHz Crystal | 14.31818 MHz | ±30ppm | ±10ppm | 20pF | 125 kOhms | Fundamental | -40°C ~ 85°C | - | Surface Mount | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.024" (0.60mm) |
|
|
0121M4-48.000FSLHPSNK2016,48.000MHZ,8.8PF,+/-7PPM,-20 |
38,420 | - |
|
Datasheet | 0121M4 | 4-SMD, No Lead | Tape & Reel (TR) | Active | MHz Crystal | 48 MHz | ±10ppm | ±7ppm | 48pF | 50 Ohms | Fundamental | -20°C ~ 70°C | - | Surface Mount | - | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.020" (0.50mm) |
|
|
3608S-32768DT09LLKTUNING FORK,8038, 32.768KHZ,9PF, |
50,800 | - |
|
Datasheet | 3608S | 4-SOJ, 5.50mm pitch | Tape & Reel (TR) | Active | kHz Crystal (Tuning Fork) | 32.768 kHz | - | ±20ppm | 9pF | 50 kOhms | Fundamental | -40°C ~ 85°C | - | Surface Mount | - | 0.315" L x 0.150" W (8.00mm x 3.80mm) | 0.098" (2.50mm) |
|
|
3426T-32768HPTLRKTUNING FORK,2X6, 32.768KHZ 12.5P |
50,800 | - |
|
Datasheet | 3426T | Cylindrical Can, Radial | Tape & Reel (TR) | Active | kHz Crystal (Tuning Fork) | 32.768 kHz | - | ±5ppm | 12.5pF | 40 kOhms | Fundamental | -20°C ~ 70°C | - | Through Hole | - | 0.079" Dia x 0.236" L (2.00mm x 6.00mm) | 0.236" (6.00mm) |
|
|
3438T-32.768DTN07LLKCRYSTAL 32.768KHZ 7PF THROGH HOL |
50,800 | - |
|
Datasheet | 3438T | Cylindrical Can, Radial | Tape & Reel (TR) | Active | kHz Crystal (Tuning Fork) | 32.768 kHz | - | ±20ppm | 7pF | 30 kOhms | Fundamental | -40°C ~ 85°C | - | Through Hole | - | 0.118" Dia x 0.315" L (3.00mm x 8.00mm) | 0.323" (8.20mm) |
|
|
0153G2-27.000F20DTLJK5032,glass,2pin,27MHz,20pF,+/-20 |
113,640 | - |
|
Datasheet | 0153G2 | 2-SMD, No Lead | Tape & Reel (TR) | Active | MHz Crystal | 27 MHz | ±30ppm | ±20ppm | 20pF | 30 Ohms | Fundamental | -40°C ~ 85°C | - | Surface Mount | - | 0.197" L x 0.126" W (5.00mm x 3.20mm) | 0.051" (1.30mm) |
Crystals FAQ
Common questions about filtering, comparing and sourcing Crystals components.
How can I narrow the Crystals selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Crystals part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
