Current Sense Transformers
Use the filters and product table below to compare Current Sense Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Frequency Range | Type | Current Rating (Amps) | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Current Ratio | DC Resistance (DCR) | Ratings | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PCS040-EF1313KSCURRENT SENSE TRANSF 40A 13300UH |
1,455 | - |
|
Datasheet | PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 13.3 mH | 317.5VµS | 1:125 | 125:1 | 1mOhm Primary, 1.85Ohm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS040-EF1302KSCURRENT SENSE TRANSF 40A 2120UH |
3,112 | - |
|
Datasheet | PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 2.12 mH | 127VµS | 1:50 | 50:1 | 1mOhm Primary, 705mOhm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS040-EF13760SCURRENT SENSE TRANSF 40A 760UH |
2,196 | - |
|
Datasheet | PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 760 µH | 76.2VµS | 1:30 | 30:1 | 1mOhm Primary, 265mOhm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS020-EE05320SCURRENT SENSE TRANSF 20A 320UH |
2,921 | - |
|
Datasheet | PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 20 A | 320 mH | 21.6VµS | 1:40 | 40:1 | 7mOhm Primary, 1.14Ohm Secondary Max | - | Surface Mount | 0.245" L x 0.235" W (6.22mm x 5.97mm) | 0.209" (5.31mm) | Gull Wing |
|
7201CURR SENSE XFMR 10A UNI TH |
3,472 | - |
|
Datasheet | 7200 | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | 0.748" L x 0.433" W (19.00mm x 11.00mm) | 0.791" (20.10mm) | - |
|
7202CURR SENSE XFMR 20A UNI TH |
2,460 | - |
|
Datasheet | 7200 | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | 0.748" L x 0.433" W (19.00mm x 11.00mm) | 0.791" (20.10mm) | - |
|
7203CURR SENSE XFMR 35A UNI TH |
4,884 | - |
|
Datasheet | 7200 | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | 0.748" L x 0.433" W (19.00mm x 11.00mm) | 0.791" (20.10mm) | - |
Current Sense Transformers FAQ
Common questions about filtering, comparing and sourcing Current Sense Transformers components.
How can I narrow the Current Sense Transformers selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Current Sense Transformers part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
