RF Diodes
Browse available RF Diodes part numbers with manufacturer references, stock information, pricing, datasheets and key specifications. Use the table below to compare options for your project.
For BOM, shortage or hard-to-find requirements, send your part number and quantity to Winsun (HK) Electronics for availability, lead-time and quotation support.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Diode Type | Voltage - Peak Reverse (Max) | Current - Max | Capacitance @ Vr, F | Resistance @ If, F | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MSS40-CR46-B49COM SCHOTTKY-BEAMLEAD, B49 |
6,609 | - |
|
Datasheet | MSS40-xxx-x | B49 | Tray | Active | Schottky - 1 Bridge | 3V | 50 mA | 0.2pF @ 0V, 1MHz | - | 100 mW | -65°C ~ 150°C | - | - | B49 |
|
MMD820-C12DIODE,SRD-CHIP, C12 |
2,528 | - |
|
Datasheet | MMDx | Die | Tray | Active | Step Recovery Diode | 40V | 150 mA | 1.7pF @ 6V, 1MHz | - | 250 mW | -65°C ~ 175°C | - | - | Chip |
|
MSS30-046-C15SCHOTTKY DIODE,CHIP, C15 |
6,813 | - |
|
Datasheet | - | Die | Tray | Active | Schottky - Single | 2V | 50 mA | 0.12pF @ 0V, 1MHz | 10Ohm @ 5mA, 1MHz | 100 mW | -65°C ~ 150°C | - | - | Chip |
|
MMPN080150DIODE,PIN,CHIP,C51 |
8,482 | - |
|
Datasheet | - | C51 | Tray | Active | PIN - Single | 200V | 150 mA | - | - | - | 175°C (TJ) | - | - | C51 |
|
MGPN1503-C01AGAAS PIN DIODES |
3,972 | - |
|
Datasheet | MGPN | Die | Tray | Obsolete | PIN - Single | 205V | 10 mA | 0.03pF @ 10V, 1MHz | 3Ohm @ 20mA, 1GHz | 400 mW | 175°C (TJ) | - | - | Chip |
|
MPN7453B-C22DIODE,PIN-CHIP, C22 |
8,415 | - |
|
Datasheet | - | Die | Tray | Active | PIN - Single | 400V | - | 0.2pF @ 50V, 100MHz | 900mOhm @ 100mA, 100MHz | - | 175°C (TJ) | - | - | Chip |
|
MPND4005-0402DIODE,PIN-BEAMLEAD-PACKAGE, 0402 |
4,157 | - |
|
Datasheet | - | 0402 (1005 Metric) | Tray | Active | PIN - Single | 100V | - | 0.02pF @ 10V, 15GHz | 6.5Ohm @ 20mA, 3GHz | 250 mW | -65°C ~ 175°C | - | - | 0402 |
|
MPND4005-B16DIODE,PIN-BEAMLEAD, B16 |
9,542 | - |
|
Datasheet | - | B16 | Tray | Active | PIN - 1 Pair Common Anode | 100V | - | 0.02pF @ 10V, 15GHz | 6.5Ohm @ 20mA, 3GHz | 250 mW | -65°C ~ 175°C | - | - | B16 |
|
|
MPN7420-T55DIODE,PIN-CHIP-PACKAGE, T55-1 |
9,242 | - |
|
Datasheet | - | T55 | Tray | Active | PIN - Single | 400V | - | 0.08pF @ 50V, 100MHz | 1.5Ohm @ 100mA, 100MHz | - | 175°C (TJ) | - | - | T55 |
|
MSS40-045-C15COM SCHOTTKY-CHIP, C15 |
7,581 | - |
|
Datasheet | - | Die | Tray | Active | Schottky - Single | 3V | 50 mA | 0.12pF @ 0V, 1MHz | 7Ohm @ 5mA, 1MHz | 100 mW | -65°C ~ 150°C | - | - | Chip |
|
MSS60-444-B42SCHOTTKY DIODE,BEAMLEAD, B42 |
8,181 | - |
|
Datasheet | - | B42 | Tray | Active | Schottky - 1 Bridge | 3.5V | 50 mA | 0.1pF @ 0V, 1MHz | 20Ohm @ 5mA, 1MHz | 100 mW | -65°C ~ 150°C | - | - | B42 |
|
|
MSS30-346-B21COM SCHOTTKY-BEAMLEAD- B21 |
8,161 | - |
|
Datasheet | - | B21 | Tray | Active | Schottky - Anti-Parallel | - | 50 mA | 0.3pF @ 0V, 1MHz | 11Ohm @ 5mA, 1MHz | 100 mW | -65°C ~ 150°C | - | - | B21 |
|
MLP7120-11LIMITER DIODE,DIE |
6,261 | - |
|
Datasheet | - | Die | Tray | Active | PIN - Single | 180V | - | 0.15pF @ 6V, 1MHz | 1.5Ohm @ 10mA, 1GHz | 5 W | -55°C ~ 150°C | - | - | Die |
|
MSS20-046-H27SCHOTTKY DIODE,CHIP-PACKAGE H27 |
4,826 | - |
|
Datasheet | - | H27 | Tray | Active | Schottky - Single | 1V | 35 mA | 0.22pF @ 0V, 1MHz | - | 100 mW | -65°C ~ 150°C | - | - | H27 |
|
MMP7022-11DIODE,PIN,DIE |
3,347 | - |
|
Datasheet | MMP7022 | Die | Tray | Active | PIN - Single | 70V | - | 0.15pF @ 10V, 1MHz | 600mOhm @ 75mA, 1MHz | - | -55°C ~ 150°C | - | - | Die |
|
MSWSH-100-30SWITCH,RF,CM22 PKG |
8,259 | - |
|
Datasheet | - | CM22 | Tray | Active | PIN - Single | 700V | - | 0.4pF @ 50V, 1MHz | 600mOhm @ 100mA, 500MHz | 100 W | 175°C (TJ) | - | - | CM22 |
|
|
MSS30-242-B20SCHOTTKY DIODE,BEAMLEAD, B20 |
5,254 | - |
|
Datasheet | - | B20 | Tray | Active | Schottky - 1 Pair Series Connection | 2V | 50 mA | 0.1pF @ 0V, 1MHz | 13Ohm @ 5mA, 1MHz | 100 mW | -65°C ~ 150°C | - | - | B20 |
|
|
MLP7120-T86LIMITER DIODE, T86 |
7,491 | - |
|
Datasheet | MLP71xx | T86 | Tray | Active | PIN - Single | 180V | - | 0.15pF @ 6V, 1MHz | 1.5Ohm @ 10mA, 1GHz | 5 W | -55°C ~ 150°C | - | - | T86 |
|
MSS30-154-E28SCHOTTKY DIODE,BEAMLEAD, E28-S |
3,694 | - |
|
Datasheet | MSS30-xxx-x | E28 | Tray | Active | Schottky - Single | 2V | 50 mA | 0.41pF @ 0V, 1MHz | 3Ohm @ 5mA, 1MHz | 100 mW | -65°C ~ 150°C | - | - | E28 |
|
|
MSS25-141-0402SCHOTTKY-BEAMLEAD-PACKAGE |
2,000 | - |
|
Datasheet | MSS25-xxx-x | 0402 (1005 Metric) | Tray | Active | Schottky - Single | 3V | - | 0.08pF @ 200mV, 1MHz | - | 150 mW | -65°C ~ 150°C | - | - | 0402 |
