Fixed Inductors
Use the filters and product table below to compare Fixed Inductors components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
82682CFIXED IND 6.8UH 640MA 270MOHM SM |
1,700 | - |
|
Datasheet | 8200 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 6.8 µH | ±20% | 640 mA | - | Unshielded | 270mOhm Max | 20 @ 1MHz | 46MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.091" (2.30mm) |
|
22R105MCFIXED IND 1MH 210MA 3.63 OHM SMD |
7,913 | - |
|
Datasheet | 2200RM | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 mH | ±10% | 210 mA | - | Unshielded | 3.63Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.311" (7.90mm) |
|
36472CFIXED IND 4.7UH 3.6A 41 MOHM SMD |
1,294 | - |
|
Datasheet | 3600 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 4.7 µH | ±25% | 3.6 A | - | Unshielded | 41mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.268" L x 0.268" W (6.80mm x 6.80mm) | 0.165" (4.20mm) |
|
39H402CFIXED IND 4UH 9.7A 8 MOHM SMD |
1,047 | - |
|
Datasheet | 3900 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 4 µH | ±20% | 9.7 A | 10.3A | Unshielded | 8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.508" L x 0.508" W (12.90mm x 12.90mm) | 0.228" (5.80mm) |
|
17105CFIXED IND 1MH 190MA 3.3 OHM TH |
274 | - |
|
Datasheet | 1700 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 1 mH | ±10% | 190 mA | - | Unshielded | 3.3Ohm Max | 120 @ 100kHz | 2.1MHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | Radial Lead | 0.283" Dia (7.20mm) | 0.413" (10.50mm) |
|
|
17104CFIXED IND 100UH 740MA 350MOHM TH |
175 | - |
|
Datasheet | 1700 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 100 µH | ±10% | 740 mA | - | Unshielded | 350mOhm Max | 90 @ 100kHz | 7MHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | Radial Lead | 0.283" Dia (7.20mm) | 0.413" (10.50mm) |
|
18R474CFIXED IND 470UH 600MA 465MOHM TH |
390 | - |
|
Datasheet | 1800R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 470 µH | ±10% | 600 mA | - | Unshielded | 465mOhm Max | 50 @ 100kHz | 2.81MHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.539" Dia (13.70mm) | 0.626" (15.90mm) |
|
|
18R104CFIXED IND 100UH 1.2A 100 MOHM TH |
301 | - |
|
Datasheet | 1800R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 100 µH | ±10% | 1.2 A | - | Unshielded | 100mOhm Max | 40 @ 100kHz | 7.4MHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.539" Dia (13.70mm) | 0.626" (15.90mm) |
|
|
18R684CFIXED IND 680UH 530MA 630MOHM TH |
200 | - |
|
Datasheet | 1800R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 680 µH | ±10% | 530 mA | - | Unshielded | 630mOhm Max | 48 @ 100kHz | 2.43MHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.539" Dia (13.70mm) | 0.626" (15.90mm) |
|
|
18R334CFIXED IND 330UH 730MA 335MOHM TH |
117 | - |
|
Datasheet | 1800R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 330 µH | ±10% | 730 mA | - | Unshielded | 335mOhm Max | 49 @ 100kHz | 3.57MHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.539" Dia (13.70mm) | 0.626" (15.90mm) |
Fixed Inductors FAQ
Common questions about filtering, comparing and sourcing Fixed Inductors components.
How can I narrow the Fixed Inductors selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Fixed Inductors part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
