Fixed Inductors
Use the filters and product table below to compare Fixed Inductors components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
60A363CFIXED IND 36UH 6.4A 20 MOHM SMD |
276 | - |
|
Datasheet | 6000A | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 36 µH | ±10% | 6.4 A | 8.8A | Unshielded | 20mOhm Max | - | 11MHz | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.748" W (22.00mm x 19.00mm) | 0.472" (12.00mm) |
|
32331CFIXED IND 330UH 780MA 215MOHM TH |
299 | - |
|
Datasheet | 3200 | Radial, Vertical, 4 Leads (Open) | Tray | Active | Toroidal | - | 330 µH | ±15% | 780 mA | - | Unshielded | 215mOhm Max | 3.2 @ 800kHz | 2.3MHz | - | -40°C ~ 125°C | 800 kHz | - | Through Hole | - | 0.846" L x 0.394" W (21.50mm x 10.00mm) | 0.945" (24.00mm) |
|
83472CFIXED IND 4.7UH 1.1A 130MOHM SMD |
4,690 | - |
|
Datasheet | 8300 | Nonstandard | Tape & Reel (TR) | Active | Toroidal | - | 4.7 µH | ±20% | 1.1 A | 1.66A | Unshielded | 130mOhm Max | - | - | - | -40°C ~ 85°C | - | - | Surface Mount | - | 0.307" L x 0.205" W (7.80mm x 5.20mm) | 0.071" (1.80mm) |
|
60B154CFIXED IND 150UH 6A 38 MOHM SMD |
285 | - |
|
Datasheet | 6000B | Nonstandard | Tray | Active | Wirewound | - | 150 µH | ±15% | 6 A | - | Unshielded | 38mOhm Max | - | 3.9MHz | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 1.063" L x 0.768" W (27.00mm x 19.50mm) | 0.787" (20.00mm) |
|
|
60B473CFIXED IND 47UH 10.5A 13 MOHM SMD |
267 | - |
|
Datasheet | 6000B | Nonstandard | Tray | Active | Wirewound | - | 47 µH | ±15% | 10.5 A | - | Unshielded | 13mOhm Max | - | 7.45MHz | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 1.063" L x 0.768" W (27.00mm x 19.50mm) | 0.787" (20.00mm) |
|
1447385CFIXED IND 47UH 8.5A 21 MOHM TH |
1,953 | - |
|
Datasheet | 1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 47 µH | ±15% | 8.5 A | - | Unshielded | 21mOhm Max | 33 @ 100kHz | 6.7MHz | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 1.055" Dia (26.80mm) | 0.610" (15.50mm) |
|
|
1447423CFIXED IND 470UH 2.3A 250 MOHM TH |
651 | - |
|
Datasheet | 1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 470 µH | ±10% | 2.3 A | - | Unshielded | 250mOhm Max | 34 @ 50kHz | 2MHz | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 1.012" Dia (25.70mm) | 0.610" (15.50mm) |
|
|
1422435CFIXED IND 220UH 3.5A 96 MOHM TH |
354 | - |
|
Datasheet | 1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 220 µH | ±10% | 3.5 A | - | Unshielded | 96mOhm Max | 22 @ 50kHz | 2.8MHz | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 1.028" Dia (26.10mm) | 0.610" (15.50mm) |
|
|
1415440CFIXED IND 150UH 4A 69 MOHM TH |
270 | - |
|
Datasheet | 1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 150 µH | ±10% | 4 A | - | Unshielded | 69mOhm Max | 24 @ 50kHz | 3.4MHz | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 1.031" Dia (26.20mm) | 0.610" (15.50mm) |
|
|
1468420CFIXED IND 680UH 2A 300 MOHM TH |
231 | - |
|
Datasheet | 1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 680 µH | ±10% | 2 A | - | Unshielded | 300mOhm Max | 23 @ 50kHz | 1.6MHz | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 1.012" Dia (25.70mm) | 0.610" (15.50mm) |
Fixed Inductors FAQ
Common questions about filtering, comparing and sourcing Fixed Inductors components.
How can I narrow the Fixed Inductors selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Fixed Inductors part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
