Fixed Inductors
Use the filters and product table below to compare Fixed Inductors components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RL187-273J-RCFIXED IND 27MH 30MA 80 OHM TH |
3,507 | - |
|
Datasheet | RL187 | Radial, Vertical Cylinder | Bulk | Obsolete | Drum Core, Wirewound | Ferrite | 27 mH | ±5% | 30 mA | - | Unshielded | 80Ohm Max | 100 @ 79.6kHz | 300kHz | - | -55°C ~ 105°C | 79.6 kHz | - | Through Hole | - | 0.315" Dia (8.00mm) | 0.441" (11.20mm) |
|
|
RL187-333J-RCFIXED IND 33MH 30MA 80 OHM TH |
2,881 | - |
|
Datasheet | RL187 | Radial, Vertical Cylinder | Bulk | Obsolete | Drum Core, Wirewound | Ferrite | 33 mH | ±5% | 30 mA | - | Unshielded | 80Ohm Max | 100 @ 79.6kHz | 300kHz | - | -55°C ~ 105°C | 79.6 kHz | - | Through Hole | - | 0.315" Dia (8.00mm) | 0.441" (11.20mm) |
|
9250A-106-RCFIXED IND 10MH 24MA 137 OHM TH |
2,203 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 10 mH | ±10% | 24 mA | 14mA | Shielded | 137Ohm Max | 40 @ 250kHz | 470kHz | - | -55°C ~ 125°C | 250 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-107-RCFIXED IND 100MH 11MA 678 OHM TH |
1,541 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 100 mH | ±10% | 11 mA | 3mA | Shielded | 678Ohm Max | 18 @ 79kHz | 110kHz | - | -55°C ~ 125°C | 79 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-126-RCFIXED IND 12MH 23MA 143 OHM TH |
4,094 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 12 mH | ±10% | 23 mA | 13mA | Shielded | 143Ohm Max | 30 @ 79kHz | 330kHz | - | -55°C ~ 125°C | 79 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-226-RCFIXED IND 22MH 17MA 274 OHM TH |
2,849 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 22 mH | ±10% | 17 mA | 9mA | Shielded | 274Ohm Max | 27 @ 79kHz | 250kHz | - | -55°C ~ 125°C | 79 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-276-RCFIXED IND 27MH 16MA 308 OHM TH |
4,963 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 27 mH | ±10% | 16 mA | 8mA | Shielded | 308Ohm Max | 27 @ 79kHz | 210kHz | - | -55°C ~ 125°C | 79 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-336-RCFIXED IND 33MH 15MA 343 OHM TH |
3,268 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 33 mH | ±10% | 15 mA | 7.5mA | Shielded | 343Ohm Max | 27 @ 79kHz | 190kHz | - | -55°C ~ 125°C | 79 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-476-RCFIXED IND 47MH 13MA 473 OHM TH |
4,453 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 47 mH | ±10% | 13 mA | 5.5mA | Shielded | 473Ohm Max | 23 @ 79kHz | 160kHz | - | -55°C ~ 125°C | 79 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-566-RCFIXED IND 56MH 13MA 512 OHM TH |
3,460 | - |
|
Datasheet | 9250A | Axial | Bulk | Obsolete | Molded | Ferrite | 56 mH | ±10% | 13 mA | 5mA | Shielded | 512Ohm Max | 23 @ 79kHz | 140kHz | - | -55°C ~ 125°C | 79 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
Fixed Inductors FAQ
Common questions about filtering, comparing and sourcing Fixed Inductors components.
How can I narrow the Fixed Inductors selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Fixed Inductors part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
