Pressure Sensors, Transducers
Browse available Pressure Sensors, Transducers part numbers with manufacturer references, stock information, pricing, datasheets and key specifications. Use the table below to compare options for your project.
For BOM, shortage or hard-to-find requirements, send your part number and quantity to Winsun (HK) Electronics for availability, lead-time and quotation support.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Applications | Pressure Type | Operating Pressure | Output Type | Output | Accuracy | Voltage - Supply | Port Size | Port Style | Features | Termination Style | Maximum Pressure | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NPI-19A-701GHSENSOR 101.53PSIG 0.1V |
2,357 | - |
|
Datasheet | NPI-19 | Cylinder | Bulk | Active | Board Mount | Vented Gauge | 101.53PSI (700kPa) | Wheatstone Bridge | 0 mV ~ 100 mV | ±0.5% | - | - | No Port | Temperature Compensated | Flex Cable | 203.05PSI (1400kPa) | -40°C ~ 125°C | - | - | - | - |
|
82-030A-CSENSOR 30PSIA 0.1V |
101 | - |
|
Datasheet | - | - | Bulk | Active | Board Mount | Absolute | 30PSI (206.84kPa) | Wheatstone Bridge | 0 mV ~ 100 mV | ±0.1% | - | - | No Port | Temperature Compensated | Cable with Connector | 90PSI (620.53kPa) | -40°C ~ 125°C | - | - | - | - |
|
BPS6C-H00SENSOR 43.51PSIA MODULE |
1,369 | - |
|
Datasheet | BPS | Module | Box | Active | - | Absolute | 7.25PSI ~ 43.51PSI (50kPa ~ 300kPa) | CAN Bus | - | ±0.580PSI (±4kPa) | 6V ~ 18V | - | No Port | - | Connector | 72.52PSI (500kPa) | -40°C ~ 105°C | - | - | - | Module |
|
HSCDRRN001ND2A5SENSOR 0.04PSID 0.08" 12BIT 8DIP |
183 | - |
|
Datasheet | TruStability® HSC | 8-DIP (0.524", 13.30mm), Dual Ports, Same Side | Bulk | Active | Board Mount | Differential | ±0.04PSI (±0.25kPa) | I2C | 12 b | ±0.25% | 4.95V ~ 5.05V | Male - 0.08" (1.93mm) Tube, Dual | Barbed | Amplified Output, Temperature Compensated | PC Pin | ±9.76PSI (±67.28kPa) | -20°C ~ 85°C | - | - | Through Hole | 8-DIP |
|
86-500G-RSENSOR 500PSIG 0.1V |
3,050 | - |
|
Datasheet | - | Cylinder | Tube | Active | Board Mount | Vented Gauge | 500PSI (3447.38kPa) | Wheatstone Bridge | 0 mV ~ 100 mV | ±0.1% | - | - | No Port | Temperature Compensated | Cable with Connector | 1500PSI (10342.14kPa) | -40°C ~ 125°C | - | - | - | - |
|
86-015G-RSENSOR 15PSIG 0.1V |
4,697 | - |
|
Datasheet | - | Cylinder | Tube | Active | Board Mount | Vented Gauge | 15PSI (103.42kPa) | Wheatstone Bridge | 0 mV ~ 100 mV | ±0.2% | - | - | - | Temperature Compensated | Cable with Connector | 45PSI (310.26kPa) | -40°C ~ 125°C | - | - | - | - |
|
|
NPI-19M-005G2SENSOR 5PSIG M12 14BIT |
1,230 | - |
|
Datasheet | NPI-19 | Cylinder | Tray | Active | Industrial Automation | Gauge | 5PSI (34.47kPa) | I2C | 14 b | ±1% | 2.5V ~ 5.5V | Male - M12 x 1.0 | Threaded | Temperature Compensated | Wire Leads | 10PSI (68.95kPa) | -10°C ~ 80°C | - | - | - | - |
|
|
NPI-19A-300G2SENSOR 300PSIG 14BIT |
1,323 | - |
|
Datasheet | NPI-19 | Cylinder | Tray | Active | Industrial Automation | Gauge | 300PSI (2068.43kPa) | I2C | 14 b | ±1% | 2.5V ~ 5.5V | - | No Port | Temperature Compensated | Wire Leads | 600PSI (4136.85kPa) | -40°C ~ 125°C | - | - | - | - |
|
|
NPI-19M-030A2SENSOR 30PSIA M12 14BIT |
2,724 | - |
|
Datasheet | NPI-19 | Cylinder | Tray | Active | Industrial Automation | Absolute | 30PSI (206.84kPa) | I2C | 14 b | ±1% | 2.5V ~ 5.5V | Male - M12 x 1.0 | Threaded | Temperature Compensated | Wire Leads | 60PSI (413.69kPa) | -40°C ~ 125°C | - | - | - | - |
|
HSCDANN100PGAA5SENSOR 100PSIG 0.19" 4.5V 8DIP |
178 | - |
|
Datasheet | TruStability® HSC | 8-DIP (0.524", 13.30mm), Top Port | Bulk | Active | Board Mount | Vented Gauge | 100PSI (689.48kPa) | Analog Voltage | 0.5 V ~ 4.5 V | ±0.25% | 4.75V ~ 5.25V | Male - 0.19" (4.93mm) Tube | Barbed | Amplified Output, Temperature Compensated | PC Pin | 250PSI (1723.69kPa) | -20°C ~ 85°C | - | - | Through Hole | 8-DIP |
|
|
NPI-15A-3K0SVSENSOR 3000PSIS 0.1V |
2,351 | - |
|
Datasheet | NPI-15VC | Cylinder | Bulk | Active | Board Mount | Sealed Gauge | 3000PSI (20684.27kPa) | Wheatstone Bridge | 0 mV ~ 100 mV (10V) | ±0.35% | 10V ~ 15V | - | No Port | Temperature Compensated | Flex Cable | 6000PSI (41368.54kPa) | -40°C ~ 125°C | - | - | - | - |
|
|
4525-DS3A001DP1PSI DP PRESSURE SENSOR 10% TO 9 |
4,783 | - |
|
Datasheet | MS4525 | 8-DIP (0.500", 12.70mm), Dual Ports, Same Side | Bulk | Active | - | Differential | 1PSI (6.89kPa) | Analog Voltage | 0.5 V ~ 4.5 V | ±1% | 3.3V | Male - 0.14" (3.56mm) Tube, Dual | Barbed | Amplified Output, Temperature Compensated | PC Pin | 20PSI (137.9kPa) | -25°C ~ 105°C | - | - | Through Hole | - |
|
|
76069-00000850-01SWITCH 90PSI SPST-NC 1/8"NPT |
4,263 | - |
|
Datasheet | 5000 | Cylinder, Threaded | Bulk | Active | - | Switch | 51PSI ~ 90PSI (351.63kPa ~ 620.53kPa) | SPST-NC | - | - | - | Male - 1/8" (3.18mm) NPT | Threaded | - | Quick Connect - 0.250" (6.3mm) | 500PSI (3447.38kPa) | -40°C ~ 121°C | - | - | - | - |
|
FMA-500-T1-05W-GVSENSOR 0.18PSI 1/8"NPT 4.5V |
3,851 | - |
|
Datasheet | FMA | Module | Bulk | Active | Board Mount | Vacuum | 0.18PSI (1.25kPa) | Analog Voltage | 0.5 V ~ 4.5 V | ±2.5% | 4.75V ~ 5.25V | Female - 1/8" (3.18mm) NPT | Barbless | Amplified Output, Temperature Compensated | Connector | 0.36PSI (2.49kPa) | -40°C ~ 125°C | - | - | - | - |
|
ADP5110SENSOR 14.5PSI 0.12" 4.5V |
159 | - |
|
Datasheet | PS-A | 6-DIP Module | Bulk | Last Time Buy | Board Mount | Vacuum | -14.5PSI (-100kPa) | Analog Voltage | 0 V ~ 4.5 V | ±1.25% | 5V | Male - 0.12" (3mm) Tube | Barbless | Amplified Output, Temperature Compensated | PC Pin | -29.01PSI (-200kPa) | -10°C ~ 60°C | - | - | Through Hole | - |
|
|
76053-B00000370-15SWITCH 50PSI SPST-NO 1/8"NPT |
1,837 | - |
|
Datasheet | 5000 | Cylinder, Threaded | Bulk | Active | - | Switch | 25PSI ~ 50PSI (172.37kPa ~ 344.74kPa) | SPST-NO | - | - | - | Male - 1/8" (3.18mm) NPT | Threaded | - | Screw Terminal | 500PSI (3447.38kPa) | -40°C ~ 121°C | - | - | - | - |
|
|
87641-B00000020-01SENSOR 2PSI |
3,663 | - |
|
Datasheet | - | - | Bulk | Active | - | - | 2PSI (13.79kPa) | - | - | - | - | - | - | - | Screw Terminal | - | - | - | - | - | - |
|
|
NPI-19A-701AHSENSOR 101.53PSIA 0.1V |
1,432 | - |
|
Datasheet | NPI-19 | Cylinder | Bulk | Active | Board Mount | Absolute | 101.53PSI (700kPa) | Wheatstone Bridge | 0 mV ~ 100 mV | ±0.5% | - | - | No Port | Temperature Compensated | Flex Cable | 203.05PSI (1400kPa) | -40°C ~ 125°C | - | - | - | - |
|
SSCDRRN002ND2A3SENSOR 0.07PSID 0.08" 12BIT 8DIP |
2,241 | - |
|
Datasheet | TruStability® SSC | 8-DIP (0.524", 13.30mm), Dual Ports, Same Side | Bulk | Active | Board Mount | Differential | ±0.07PSI (±0.5kPa) | I2C | 12 b | ±0.25% | 3.27V ~ 3.33V | Male - 0.08" (1.93mm) Tube, Dual | Barbed | Amplified Output, Temperature Compensated | PC Pin | ±9.76PSI (±67.28kPa) | -40°C ~ 85°C | - | - | Through Hole | 8-DIP |
|
82-015G-CSENSOR 15PSIG 0.1V |
4,824 | - |
|
Datasheet | - | - | Tube | Active | Board Mount | Vented Gauge | 15PSI (103.42kPa) | Wheatstone Bridge | 0 mV ~ 100 mV | ±0.1% | - | - | No Port | Temperature Compensated | Cable with Connector | 45PSI (310.26kPa) | -40°C ~ 125°C | - | - | - | - |
Pressure Sensors, Transducers FAQ
Common questions about selecting, comparing and sourcing Pressure Sensors, Transducers components through Winsun (HK) Electronics.
What should I check when selecting Pressure Sensors, Transducers components?
Compare the manufacturer part number, electrical specifications, package, operating conditions and application requirements. The product datasheet should be used to confirm technical suitability.
Can Winsun help source specific Pressure Sensors, Transducers part numbers?
Yes. Send the exact part number, manufacturer and required quantity. Winsun (HK) Electronics can assist with availability checks, quotation support and sourcing options based on your requirement.
Do you support shortage, obsolete or hard-to-find Pressure Sensors, Transducers parts?
Yes. Our sourcing team can review shortage and obsolete-part requirements and help check available supply channels or possible alternatives when appropriate.
How do I request a quote for Pressure Sensors, Transducers components?
Submit an RFQ with the part number, manufacturer, quantity and target delivery requirement. Our sales team will review your request and follow up with current sourcing information.
