SCRs - Modules
Use the filters and product table below to compare SCRs - Modules components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TD390N18SOFHPSA1SCR MODULE 1.8KV 520A MODULE |
3 | - |
|
Datasheet | - | Module | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.8 kV | 380 A | 520 A | 2 V | 150 mA | 9500A @ 50Hz | 150 mA | -40°C ~ 125°C (TC) | - | - | Chassis Mount |
|
T390N14TOFXPSA1SCR MODULE 1600V 600A DO200AA |
22 | - |
|
Datasheet | - | TO-200AA | Tray | Active | Single | 1 SCR | 1.6 kV | 381 A | 600 A | 2 V | 150 mA | 4900A @ 50Hz | 200 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
|
T470N16TOFXPSA1SCR MODULE 1600V 800A DO200AA |
18 | - |
|
Datasheet | - | TO-200AA | Tray | Active | Single | 1 SCR | 1.6 kV | 470 A | 800 A | 2 V | 200 mA | 7100A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Chassis Mount |
|
|
TD390N16SOFHPSA1LA-T-BOND MODULE |
18 | - |
|
Datasheet | - | Module | Tray | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | 380 A | 520 A | 2 V | 150 mA | 9500A @ 50Hz | 150 mA | -40°C ~ 125°C (TC) | - | - | Chassis Mount |
|
TT390N16SOFHPSA1LA-T-BOND MODULE |
4 | - |
|
Datasheet | - | Module | Tray | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 380 A | 520 A | 2 V | 150 mA | 9500A @ 50Hz | 150 mA | -40°C ~ 125°C (TC) | - | - | Chassis Mount |
|
T420N16TOFXPSA1SCR MODULE 1800V 750A DO200AA |
6 | - |
|
Datasheet | - | DO-200AA, A-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 424 A | 750 A | 2 V | 200 mA | 7200A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
T640N16TOFXPSA1SCR MODULE 1800V 1250A DO200AA |
12 | - |
|
Datasheet | - | DO-200AA, A-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 644 A | 1250 A | 2.2 V | 250 mA | 9400A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
T640N14TOFXPSA1SCR MODULE 1800V 1250A DO200AA |
6 | - |
|
Datasheet | - | DO-200AA, A-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 644 A | 1250 A | 2.2 V | 250 mA | 9400A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
T940N16TOFXPSA1SCR MODULE 1800V 1759A DO200AB |
18 | - |
|
Datasheet | - | DO-200AB, B-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 959 A | 1759 A | 2.2 V | 250 mA | 17500A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
|
T720N16TOFXPSA1SCR MODULE 1800V 1500A DO200AB |
6 | - |
|
Datasheet | - | DO-200AB, B-PUK | Tray | Active | Single | 1 SCR | 1.8 kV | 720 A | 1500 A | 1.5 V | 250 mA | 14500A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
SCRs - Modules FAQ
Common questions about filtering, comparing and sourcing SCRs - Modules components.
How can I narrow the SCRs - Modules selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific SCRs - Modules part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
