Audio Transformers
Browse available Audio Transformers part numbers with manufacturer references, stock information, pricing, datasheets and key specifications. Use the table below to compare options for your project.
For BOM, shortage or hard-to-find requirements, send your part number and quantity to Winsun (HK) Electronics for availability, lead-time and quotation support.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Turns Ratio - Primary:Secondary | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) | DC Resistance (DCR) - Primary | DC Resistance (DCR) - Secondary | Transformer Type | Frequency Range | Frequency Response | Voltage - Isolation | Insertion Loss | Return Loss | Power Level | Operating Temperature | Approval Agency | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
106RAUDIO XFMR 48CT / 8 TH |
1,378 | - |
|
Datasheet | 106 | Bulk | Active | - | 48CT | 8 | 2.4Ohm | 700mOhm | Miniature Epoxy Potted | 170Hz | -1dB | 200V | 1dB | - | 1.5W | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
|
106GAUDIO XFMR 4K / 600CT TH |
4,720 | - |
|
Datasheet | 106 | Bulk | Active | - | 4k | 600CT | 340Ohm | 24Ohm | Miniature Epoxy Potted | 215Hz | -1dB | 200V | 1dB | - | 150mW | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
|
106MAUDIO XFMR 20K / 2KCT TH |
4,464 | - |
|
Datasheet | 106 | Bulk | Active | - | 20k | 2kCT | 1.18kOhm | 89Ohm | Miniature Epoxy Potted | 215Hz | -1dB | 200V | 1dB | - | 150mW | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
117E8AUDIO XFMR 3.2 / 70V CHAS MNT |
3,159 | - |
|
Datasheet | 117 | Bulk | Active | - | 3.2 | 70V | - | - | Sound Distribution | 100Hz ~ 9kHz | 1dB | - | 2dB | - | 8W | - | - | Chassis Mount | 3.250" L x 1.750" W (82.55mm x 44.45mm) | 2.000" (50.80mm) | Solder Lug |
|
|
117J8AUDIO XFMR 3.2 / 25V CHAS MNT |
1,405 | - |
|
Datasheet | 117 | Bulk | Active | - | 3.2 | 25V | - | - | Sound Distribution | 100Hz ~ 9kHz | 1dB | - | 2dB | - | 8W | - | - | Chassis Mount | 3.250" L x 1.750" W (82.55mm x 44.45mm) | 2.000" (50.80mm) | Solder Lug |
|
6W68HFAUDIO XFMR |
4,546 | - |
|
Datasheet | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
106WAUDIO XFMR 500CT / 3.2 TH |
1,519 | - |
|
Datasheet | 106 | Bulk | Active | - | 500CT | 3.2 | 26Ohm | 300mOhm | Miniature Epoxy Potted | 170Hz | -1dB | 200V | 1dB | - | 1.5W | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
143JAUDIO XFMR 3K / 1KCT CHAS MNT |
4,956 | - |
|
Datasheet | 143 | Bulk | Active | - | 3k | 1kCT | 265Ohm | 53Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143HAUDIO XFMR 1.5K / 500CT CHAS MNT |
3,224 | - |
|
Datasheet | 143 | Bulk | Active | - | 1.5k | 500CT | 111Ohm | 24Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143BAUDIO XFMR 3.2 / 4K CHAS MNT |
4,252 | - |
|
Datasheet | 143 | Bulk | Active | - | 3.2 | 4k | 400mOhm | 245Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 15mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143NAUDIO XFMR 10K / 2KCT CHAS MNT |
2,587 | - |
|
Datasheet | 143 | Bulk | Active | - | 10k | 2kCT | 720Ohm | 89Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143LAUDIO XFMR 10K / 200CT CHAS MNT |
3,180 | - |
|
Datasheet | 143 | Bulk | Active | - | 10k | 200CT | 720Ohm | 9Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
1140-LU-BAUDIO XFMR 600 / 600 CHAS MNT |
3,141 | - |
|
Datasheet | 1140 | Bulk | Active | 1:1 | 600 | 600 | 58Ohm | 58Ohm | Line (Audio Power Distribution) | 20Hz ~ 20kHz | - | 250V | - | - | - | - | - | Chassis Mount | 1.450" L x 1.063" W (36.83mm x 27.00mm) | 1.190" (30.23mm) | Wire Leads |
|
|
1750BBTRANSFORMERS/FILTERS/FERRITE |
1,164 | - |
|
Datasheet | * | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
6K112HFAUDIO XFMR |
3,399 | - |
|
Datasheet | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
T-050100TBALUNS |
4,504 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1750PAAUDIO XFMR 4, 8, 16 CHAS MNT |
3,322 | - |
|
Datasheet | 1750 | Bulk | Active | - | - | 4, 8, 16 | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | - | 1500V | - | - | - | -40°C ~ 105°C | - | Chassis Mount | - | - | Wire Leads |
|
|
1140-LU-DAUDIO XFMR 600 / 600 CHAS MNT |
2,101 | - |
|
Datasheet | 1140 | Bulk | Active | 1:1 | 600 | 600 | 40Ohm | 40Ohm | Line (Audio Power Distribution) | 20Hz ~ 20kHz | - | 250V | - | - | - | - | - | Chassis Mount | 1.700" L x 1.190" W (43.18mm x 30.23mm) | 1.380" (35.05mm) | Wire Leads |
|
|
124FAUDIO XFMR CHAS MNT |
3,537 | - |
|
Datasheet | 124 | Bulk | Active | - | - | - | 900Ohm | - | Tube Driver and Speaker Matching | 150Hz ~ 15kHz | - | 500Vrms | - | - | 5W | - | - | Chassis Mount | - | 2.370" (60.20mm) | Wire Leads |
|
|
1750SAUDIO XFMR 5.1K / 8 CHAS MNT |
2,384 | - |
|
Datasheet | 175 | Bulk | Active | - | 5.1k | 8 | 380Ohm | 750mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 50Hz ~ 12kHz | -4dB | 1500V | - | - | 25W | -40°C ~ 105°C | - | Chassis Mount | 3.125" L x 2.120" W (79.38mm x 53.85mm) | 2.308" (58.62mm) | Wire Leads |
Audio Transformers FAQ
Common questions about selecting, comparing and sourcing Audio Transformers components through Winsun (HK) Electronics.
What should I check when selecting Audio Transformers components?
Compare the manufacturer part number, electrical specifications, package, operating conditions and application requirements. The product datasheet should be used to confirm technical suitability.
Can Winsun help source specific Audio Transformers part numbers?
Yes. Send the exact part number, manufacturer and required quantity. Winsun (HK) Electronics can assist with availability checks, quotation support and sourcing options based on your requirement.
Do you support shortage, obsolete or hard-to-find Audio Transformers parts?
Yes. Our sourcing team can review shortage and obsolete-part requirements and help check available supply channels or possible alternatives when appropriate.
How do I request a quote for Audio Transformers components?
Submit an RFQ with the part number, manufacturer, quantity and target delivery requirement. Our sales team will review your request and follow up with current sourcing information.
