Pulse Transformers
Use the filters and product table below to compare Pulse Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HX4110NLTRANSF MOD 2.55G 4CH 60W POE |
539 | - |
|
Datasheet | - | Tube | Active | General Purpose | 120µH | - | 1CT:1CT | Surface Mount | 0.650" L x 0.360" W (16.51mm x 9.14mm) | 0.082" (2.08mm) | - | - | - |
|
H1174FNLTPULSE XFMR 1CT:1CT TX 1CT:1CT RX |
1,899 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | LAN 10/100 Base-T | - | - | 1CT:1CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.515" L x 0.574" W (13.08mm x 14.57mm) | 0.145" (3.69mm) | 0°C ~ 70°C | - | - |
|
HM5004ENLXFMR MDL 1000BASE-T SMT AEC-Q200 |
535 | - |
|
Datasheet | - | Tube | Active | LAN 1000 Base-T | 350µH | - | - | Surface Mount | 0.695" L x 0.480" W (17.65mm x 12.20mm) | 0.225" (5.72mm) | -40°C ~ 105°C | - | - |
|
HM5004ENLTMDL SIN 1GD 1:1 SMT TR |
1,200 | - |
|
Datasheet | HX5004NL | Tape & Reel (TR) | Active | LAN 1000 Base-T | 350µH | - | 1:1 | Surface Mount | 0.695" L x 0.480" W (17.65mm x 12.20mm) | 0.225" (5.72mm) | -40°C ~ 105°C | - | - |
|
H1164NLMODULE XFRMR ETHERNET LAN 40SOIC |
1,283 | - |
|
Datasheet | - | Tube | Active | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.125" L x 0.480" W (28.58mm x 12.19mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
HX5008FNLPULSE XFMR 1CT:1 TX 1CT:1 RX |
2,837 | - |
|
Datasheet | - | Tube | Active | LAN 10/100/1000 Base-T | 325µH | - | 1CT:1 Transmitter, 1CT:1 Receiver | Surface Mount | 0.518" L x 0.703" W (13.16mm x 17.86mm) | 0.241" (6.12mm) | -40°C ~ 85°C | - | - |
|
HX5008NLMODULE SINGLE GIGABIT LAN 24SOIC |
2,146 | - |
|
Datasheet | - | Tube | Active | Isolation and Data Interface (Encapsulated) | - | - | 1:1 | Surface Mount | 0.518" L x 0.595" W (13.16mm x 15.11mm) | 0.251" (6.37mm) | -40°C ~ 85°C | - | - |
|
|
H1164NLTXFRMR MODUL AUTO MDI/MDIX 10/100 |
2,007 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.125" L x 0.480" W (28.58mm x 12.19mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
HX5200NLXFRMR MODL 2PORT POE GIGABIT |
1,709 | - |
|
Datasheet | - | Tray | Active | Isolation and Data Interface (Encapsulated) | - | - | - | Surface Mount | 0.580" L x 0.680" W (14.73mm x 17.27mm) | 0.430" (10.92mm) | -40°C ~ 85°C | - | - |
|
HX5200NLTXFRMR MODULE DUAL1GP 1:1 . BGA |
300 | - |
|
Datasheet | HX5200NLT | Tape & Reel (TR) | Active | LAN 1G Base-T, Power over Ethernet (PoE) | 350µH | - | 1CT:1CT | Surface Mount | 0.580" L x 0.680" W (14.73mm x 17.27mm) | 0.440" (11.18mm) | -40°C ~ 85°C | - | - |
