RF Antennas
Use the filters and product table below to compare RF Antennas components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ARM52211DMRF ANT 829MHZ/1.582GHZ MOD PANEL |
1,839 | - |
|
Datasheet | ARMADILLO | Bulk | Active | Cellular, Navigation, WiFi | Wide Band | 829MHz, 1.582GHz, 2.2GHz, 2.45GHz, 5.537GHz | 698MHz ~ 960MHz, 1.559GHz ~ 1.606GHz, 1.71GHz ~ 2.69GHz, 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.925GHz | Module | 5 | 2, 2.5 | - | 4.9dBi, 5.3dBi, 4.6dBi, 6.6dBi | - | Cable - 5.18m, LNA | SMA Male (3), RP-SMA Male (2) | IP67 | - | - | Panel Mount | 1.772" (45.00mm) | GPS, LTE, Wi-Fi |
|
GPSMB502RF ANT MODULE RP-SMA MALE PAN MT |
4,818 | - |
|
Datasheet | - | Bag | Active | Cellular, Navigation, WiFi | Wide Band | - | - | Module | 6 | 1.5 | - | 5dBi | - | LNA, Filter | RP-SMA Male, SMA Male | IP67 | - | - | Panel Mount | 2.992" (76.00mm) | GPS, LTE, Wi-Fi |
|
W3714RF ANT 5.45GHZ PCB TRACE SLDR |
2,722 | - |
|
Datasheet | Embedded Antenna | Tape & Reel (TR) | Active | - | SHF (f > 4GHz) | 5.45GHz | 4.9GHz ~ 6GHz | PCB Trace | 1 | 2 | - | 4.5dBi | 5 W | - | Solder | - | - | - | Surface Mount | 0.094" (2.40mm) | General Purpose |
|
|
W3713RF ANT 5.45GHZ PCB TRACE SLDR |
2,720 | - |
|
Datasheet | Embedded Antenna | Tape & Reel (TR) | Active | - | SHF (f > 4GHz) | 5.45GHz | 4.9GHz ~ 6GHz | PCB Trace | 1 | 2 | - | 4.5dBi | 5 W | - | Solder | - | - | - | Surface Mount | 0.094" (2.40mm) | General Purpose |
|
|
W3716RF ANT 2.45GHZ PCB TRACE SLDR |
2,409 | - |
|
Datasheet | Embedded PCB Ant | Bag | Active | - | UHF (2GHz ~ 3GHz) | 2.45GHz | 2.4GHz ~ 2.5GHz | PCB Trace | 1 | 1.6 | - | 3dBi | 2 W | - | Solder | - | - | - | Surface Mount | 0.063" (1.60mm) | General Purpose |
|
W3403ANT EMBD METAL STAMP 868-920MHZ |
2,864 | - |
|
Datasheet | EMBEDDED SMT | Tape & Reel (TR) | Active | General ISM | UHF (300MHz ~ 1GHz) | 894MHz | 868MHz ~ 920MHz | Stamped Metal | 1 | 2 | -12dB | -1.9dBi | - | - | Solder | - | - | - | Surface Mount | 0.189" (4.80mm) | Sigfox |
|
|
W3014RF ANT 920MHZ CHIP SOLDER SMD |
949 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | - | UHF (300MHz ~ 1GHz) | 920MHz | 880MHz ~ 960MHz | Chip | 1 | - | -7dB | -0.5dBi | - | - | Solder | - | - | - | Surface Mount | 0.059" (1.50mm) | - |
|
W3078RF ANT 2.4GHZ/5GHZ CHIP SLDR SMD |
1,388 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | 802.15.4, WiFi | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) | 2.4GHz, 5GHz | 2.4GHz ~ 2.484GHz, 4.95GHz ~ 5.85GHz | Chip | 2 | - | -10dB, -6dB | 1.7dBi, 4.3dBi | - | - | Solder | - | - | - | Surface Mount | 0.043" (1.10mm) | WLAN, Zigbee™ |
|
W3062ARF ANT 1.575GHZ CHIP SOLDER SMD |
2,053 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.575GHz | 1.565GHz ~ 1.585GHz | Chip | 1 | - | -10dB | 2.5dBi | - | - | Solder | - | - | - | Surface Mount | 0.063" (1.60mm) | GPS |
|
|
W3225ANT CERAMIC PATC H 25X25X4MM GPS |
1,600 | - |
|
Datasheet | Ceramic Patch | Tape & Reel (TR) | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.575GHz, 1.602GHz | 1.574GHz ~ 1.576GHz, 1.598GHz ~ 1.606GHz | Ceramic Patch | 2 | - | -10dB | 3dBi | - | - | Solder | - | - | - | Surface Mount | 0.157" (4.00mm) | GLONASS, GPS |
RF Antennas FAQ
Common questions about filtering, comparing and sourcing RF Antennas components.
How can I narrow the RF Antennas selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific RF Antennas part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
