Audio Transformers
Use the filters and product table below to compare Audio Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Turns Ratio - Primary:Secondary | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) | DC Resistance (DCR) - Primary | DC Resistance (DCR) - Secondary | Transformer Type | Frequency Range | Frequency Response | Voltage - Isolation | Insertion Loss | Return Loss | Power Level | Operating Temperature | Approval Agency | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1760FXFMR 6.95KCT / 4, 8, 16 CHAS MNT |
3,999 | - |
|
Datasheet | 1760 | Box | Active | 29.19:1 | 6.95kCT | 4, 8, 16 | 120Ohm | 171mOhm, 245mOhm, 476mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | ±1dB | - | - | - | 15W | - | - | Chassis Mount | 3.250" L x 1.687" W (82.55mm x 42.85mm) | 2.058" (52.27mm) | Wire Leads |
|
560CXFMR 48 12/12 / 600 150/150 TH |
2,023 | - |
|
Datasheet | 560 | Bulk | Active | - | 48, 12/12 | 600, 150/150 | - | - | Broadcast Quality | 30Hz ~ 30kHz | ±1dB | - | 1dB Max | - | - | - | - | Through Hole | 1.330" L x 1.640" W (33.78mm x 41.66mm) | 0.850" (21.59mm) | PC Pin |
|
|
560EXFMR 200 50/50 / 600 150/150 TH |
2,830 | - |
|
Datasheet | 560 | Bulk | Active | - | 200, 50/50 | 600, 150/150 | - | - | Broadcast Quality | 30Hz ~ 30kHz | ±1dB | - | 1dB Max | - | - | - | - | Through Hole | 1.330" L x 1.640" W (33.78mm x 41.66mm) | 0.850" (21.59mm) | PC Pin |
|
1750NAAUDIO XFMR 6KCT / 8, 16 CHAS MNT |
3,122 | - |
|
Datasheet | 1750 | Bulk | Active | - | 6kCT | 8, 16 | 73.2Ohm, 74.41Ohm, 147.4Ohm | 300mOhm, 580mOhm, 820mOhm | - | 50Hz ~ 12kHz | ±1dB | 2500V @ 1 Second | - | - | 30W | - | - | Chassis Mount | 3.000" L x 2.465" W (76.20mm x 62.61mm) | 2.525" (64.14mm) | Solder Lug |
|
125ASEXFMR 2.5K-10K / 4-32 CHAS MNT |
2,615 | - |
|
Datasheet | 125SE | Bulk | Active | - | 2.5k ~ 10k | 4 ~ 32 | 241.7 Ohm | 229mOhm, 323mOhm, 463mOhm, 670mOhm | General Purpose | 100Hz ~ 15kHz | ±1dB | 1500V @ 1 Second | - | - | 3W | - | - | Chassis Mount | 2.810" L x 1.350" W (71.37mm x 34.29mm) | 1.690" (42.93mm) | Wire Leads |
|
118944AUDIO XFMR |
2,707 | - |
|
Datasheet | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
124BAUDIO XFMR 10K / 90KCT CHAS MNT |
4,693 | - |
|
Datasheet | 124 | Bulk | Active | 1:3 | 10k | 90kCT | 405Ohm | 1.525kOhm | Tube Driver and Speaker Matching | 150Hz ~ 15kHz | ±1dB | 500Vrms | - | - | 5W | - | - | Chassis Mount | 2.380" L x 1.350" W (60.45mm x 34.29mm) | 1.430" (36.32mm) | Wire Leads |
|
125CSEXFMR 2.5K-10K / 4-32 CHAS MNT |
2,346 | - |
|
Datasheet | 125SE | Bulk | Active | - | 2.5k ~ 10k | 4 ~ 32 | - | - | General Purpose | 100Hz ~ 15kHz | ±1dB | - | - | - | 8W | - | - | Chassis Mount | 3.690" L x 1.860" W (93.73mm x 47.24mm) | 2.310" (58.67mm) | Wire Leads |
|
1750JAUDIO XFMR 4KCT / 4 CHAS MNT |
4,649 | - |
|
Datasheet | 1750 | Box | Active | 31.11:1 | 4kCT | 4 | 185Ohm | 400mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | ±1dB | - | - | - | 35W | - | - | Chassis Mount | 4.076" L x 3.170" W (103.53mm x 80.52mm) | 2.630" (66.80mm) | Wire Leads |
|
|
1760JXFMR 4KCT / 4, 8, 16 CHAS MNT |
3,081 | - |
|
Datasheet | 1760 | Box | Active | 31.11:1 | 4kCT | 4, 8, 16 | 185Ohm | 400mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | ±1dB | - | - | - | 35W | - | - | Chassis Mount | 4.076" L x 3.170" W (103.53mm x 80.52mm) | 3.513" (89.23mm) | Wire Leads |
