FET, MOSFET Arrays
Use the filters and product table below to compare FET, MOSFET Arrays components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Configuration | FET Feature | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Power - Max | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MSCSM170AM039CD3AGMOSFET 2N-CH 1700V 523A |
2 | - |
|
Datasheet | - | Module | Bulk | Active | Silicon Carbide (SiC) | 2 N Channel (Phase Leg) | - | 1700V (1.7kV) | 523A (Tc) | 5mOhm @ 270A, 20V | 3.3V @ 22.5mA | 1602nC @ 20V | 29700pF @ 1000V | 2.4kW (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | - |
|
APTM50H14FT3GMOSFET 4N-CH 500V 26A SP3 |
13 | - |
|
Datasheet | - | SP3 | Bulk | Active | MOSFET (Metal Oxide) | 4 N-Channel (Full Bridge) | - | 500V | 26A | 168mOhm @ 13A, 10V | 5V @ 1mA | 72nC @ 10V | 3259pF @ 25V | 208W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP3 |
|
APTC60DSKM24T3GMOSFET 2N-CH 600V 95A SP3 |
7 | - |
|
Datasheet | CoolMOS™ | SP3 | Tray | Active | MOSFET (Metal Oxide) | 2 N Channel (Dual Buck Chopper) | - | 600V | 95A | 24mOhm @ 47.5A, 10V | 3.9V @ 5mA | 300nC @ 10V | 14400pF @ 25V | 462W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP3 |
|
APTM50HM65FT3GMOSFET 4N-CH 500V 51A SP3 |
8 | - |
|
Datasheet | - | SP3 | Bulk | Active | MOSFET (Metal Oxide) | 4 N-Channel (Full Bridge) | - | 500V | 51A | 78mOhm @ 25.5A, 10V | 5V @ 2.5mA | 140nC @ 10V | 7000pF @ 25V | 390W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP3 |
|
APTM50AM38STGMOSFET 2N-CH 500V 90A SP4 |
6 | - |
|
Datasheet | - | SP4 | Bulk | Active | MOSFET (Metal Oxide) | 2 N-Channel (Half Bridge) | - | 500V | 90A | 45mOhm @ 45A, 10V | 5V @ 5mA | 246nC @ 10V | 11200pF @ 25V | 694W | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | SP4 |
|
|
MSCSM70TLM19C3AGMOSFET 4N-CH 700V 124A SP3F |
5 | - |
|
Datasheet | - | Module | Bulk | Active | Silicon Carbide (SiC) | 4 N-Channel (Three Level Inverter) | - | 700V | 124A (Tc) | 19mOhm @ 40A, 20V | 2.4V @ 4mA | 215nC @ 20V | 4500pF @ 700V | 365W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | SP3F |
|
|
MSCSM70VR1M10CT3AGMOSFET 2N-CH 700V 241A |
4 | - |
|
Datasheet | - | Module | Bulk | Active | Silicon Carbide (SiC) | 2 N Channel (Phase Leg) | - | 700V | 241A (Tc) | 9.5mOhm @ 80A, 20V | 2.4V @ 8mA | 430nC @ 20V | 9000pF @ 700V | 690W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | - |
|
MSCM20XM10T3XGMOSFET 6N-CH 200V 108A SP3X |
9 | - |
|
Datasheet | - | Module | Bulk | Active | MOSFET (Metal Oxide) | 6 N-Channel (3-Phase Bridge) | - | 200V | 108A (Tc) | 9.7mOhm @ 81A, 10V | 5V @ 250µA | 161nC @ 10V | 10700pF @ 50V | 341W (Tc) | -40°C ~ 125°C (Tc) | - | - | Chassis Mount | SP3X |
.jpg "MSCSM120HM31CT3AG")
|
MSCSM120HM31CT3AGMOSFET 4N-CH 1200V 89A SP3F |
3 | - |
|
Datasheet | - | Module | Tube | Active | Silicon Carbide (SiC) | 4 N-Channel | - | 1200V (1.2kV) | 89A (Tc) | 31mOhm @ 40A, 20V | 2.8V @ 1mA | 232nC @ 20V | 3020pF @ 1000V | 395W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | SP3F |
|
MSCSM70AM07CT3AGMOSFET 2N-CH 700V 353A SP3F |
3 | - |
|
Datasheet | - | Module | Tube | Active | Silicon Carbide (SiC) | 2 N Channel (Phase Leg) | - | 700V | 353A (Tc) | 6.4mOhm @ 120A, 20V | 2.4V @ 12mA | 645nC @ 20V | 13500pF @ 700V | 988W (Tc) | -40°C ~ 175°C (TJ) | - | - | Chassis Mount | SP3F |
FET, MOSFET Arrays FAQ
Common questions about filtering, comparing and sourcing FET, MOSFET Arrays components.
How can I narrow the FET, MOSFET Arrays selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific FET, MOSFET Arrays part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
