Audio Transformers
Use the filters and product table below to compare Audio Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Turns Ratio - Primary:Secondary | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) | DC Resistance (DCR) - Primary | DC Resistance (DCR) - Secondary | Transformer Type | Frequency Range | Frequency Response | Voltage - Isolation | Insertion Loss | Return Loss | Power Level | Operating Temperature | Approval Agency | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1760LXFMR 4.2KCT / 4, 8, 16 CHAS MNT |
1,669 | - |
|
Datasheet | 1760 | Box | Active | 31.16:1 | 4.2kCT | 4, 8, 16 | 46.48Ohm, 51.04Ohm | 252mOhm, 480mOhm, 714mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | ±1dB | - | - | - | 60W | - | - | Chassis Mount | 4.050" L x 3.150" W (102.87mm x 80.01mm) | 3.193" (81.10mm) | Wire Leads |
|
1750NXFMR 3.2KCT / 4, 8, 16 CHAS MNT |
1,437 | - |
|
Datasheet | 1750 | Box | Active | 14.30:1 | 3.2kCT | 4, 8, 16 | 41.74Ohm, 3.14Ohm | 170mOhm, 240mOhm, 360mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | ±1dB | - | - | - | 50W | - | - | Chassis Mount | 3.125" L x 3.350" W (79.38mm x 85.09mm) | 3.800" (96.52mm) | Wire Leads |
|
126BAUDIO XFMR 5K / 5K CHAS MNT |
2,528 | - |
|
Datasheet | 126 | Box | Active | - | 5k | 5k | 178Ohm | 178Ohm | Single Ended Audiophile, Ultra-Linear - Tube Output | 20Hz ~ 20kHz | ±1dB | 400VDC | - | - | 4W | - | - | Chassis Mount | 3.120" L x 2.500" W (79.25mm x 63.50mm) | 3.120" (79.25mm) | Wire Leads |
|
|
1760WXFMR 2KCT / 4, 8, 16 CHAS MNT |
2,271 | - |
|
Datasheet | 1760 | Box | Active | 22.35:1 | 2kCT | 4, 8, 16 | 11.4Ohm | 100mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | ±1dB | - | - | - | 100W | - | - | Chassis Mount | 4.050" L x 3.465" W (102.87mm x 88.01mm) | 3.563" (90.50mm) | Wire Leads |
|
|
1750WAUDIO XFMR 2KCT / 4 CHAS MNT |
2,634 | - |
|
Datasheet | 1750 | Box | Active | 22.35:1 | 2kCT | 4 | 11.4Ohm | 100mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | ±1dB | - | - | - | 100W | - | - | Chassis Mount | 4.063" L x 3.450" W (103.20mm x 87.63mm) | 3.563" (90.50mm) | Wire Leads |
|
|
1750XXFMR 2KCT / 2, 4, 8, 16 CHAS MNT |
4,587 | - |
|
Datasheet | 1750 | Box | Active | 10.14:1 | 2kCT | 2, 4, 8, 16 | 5.03Ohm, 12.3Ohm, 7.16Ohm | 20mOhm, 30mOhm, 50mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 50Hz ~ 12kHz | ±1dB | - | - | - | 100W | - | - | Chassis Mount | 3.786" L x 4.049" W (96.16mm x 102.84mm) | 3.238" (85.25mm) | Solder Lug |
|
1650HXFMR 6.6KCT / 4, 8, 16 CHAS MNT |
2,032 | - |
|
Datasheet | 1600 | Bulk | Active | - | 6.6kCT | 4, 8, 16 | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | - | ±1dB | - | 40W | - | - | Chassis Mount | 4.000" L x 3.130" W (101.60mm x 79.50mm) | 3.810" (96.77mm) | Wire Leads |
|
1650HAXFMR 6.6KCT / 4, 8, 16 CHAS MNT |
3,400 | - |
|
Datasheet | A | Box | Active | - | 6.6kCT | 4, 8, 16 | 63.69Ohm, 71.33Ohm | 74mOhm, 223mOhm, 258mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | 2000V @ 1 Second | - | - | 40W | - | - | Chassis Mount | 4.000" L x 3.130" W (101.60mm x 79.50mm) | 3.810" (96.77mm) | Wire Leads |
|
|
1645AXFMR 5KCT / 4, 8, 16, 70V CHAS |
1,906 | - |
|
Datasheet | A | Box | Active | - | 5kCT | 4, 8, 16, 70V | 72.11Ohm, 79.35Ohm | 276mOhm, 391mOhm, 464mOhm, 9.304Ohm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | 2000V @ 1 Second | - | - | 30W | - | - | Chassis Mount | 3.750" L x 2.500" W (95.25mm x 63.50mm) | 3.060" (77.72mm) | Wire Leads |
|
1627SEAXFMR 2.5K / 4, 8, 16 CHAS MNT |
4,113 | - |
|
Datasheet | 1600 | Box | Active | - | 2.5k | 4, 8, 16 | 30Ohm, 47.44Ohm | 402mOhm, 502mOhm, 700mOhm | Single Ended Audiophile, Ultra-Linear - Tube Output | 20Hz ~ 20kHz | ±1dB | 2828VDC @ 1 Second | ±1dB | - | 30W | - | - | Chassis Mount | 4.500" L x 3.750" W (114.30mm x 95.25mm) | 4.560" (115.82mm) | Wire Leads |
