Audio Transformers
Use the filters and product table below to compare Audio Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Turns Ratio - Primary:Secondary | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) | DC Resistance (DCR) - Primary | DC Resistance (DCR) - Secondary | Transformer Type | Frequency Range | Frequency Response | Voltage - Isolation | Insertion Loss | Return Loss | Power Level | Operating Temperature | Approval Agency | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1628SEAAUDIO XFMR 5K / 4, 8, 16 CHAS MT |
3,261 | - |
|
Datasheet | 1600 | Box | Active | - | 5k | 4, 8, 16 | - | - | Single Ended Audiophile, Ultra-Linear - Tube Output | 20Hz ~ 20kHz | ±1dB | 2000Vrms | ±1dB | - | 30W | - | - | Chassis Mount | 4.500" L x 3.750" W (114.30mm x 95.25mm) | 4.560" (115.82mm) | Wire Leads |
|
|
1642SEAUDIO XFMR 5K / 4, 8, 16 CHAS MT |
2,331 | - |
|
Datasheet | 1600 | Bulk | Active | - | 5k | 4, 8, 16 | - | - | Single Ended Audiophile | 20Hz ~ 20kHz | ±1dB | 3500Vrms | ±1dB | - | 75W | - | - | Chassis Mount | 7.500" L x 4.380" W (190.50mm x 111.25mm) | 5.250" (133.35mm) | Wire Leads |
|
144IAUDIO XFMR 600CT / 150CT CHAS MT |
1,937 | - |
|
Datasheet | 144 | Bulk | Active | - | 600CT | 150CT | 45Ohm | 8.2Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 150mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
107GAUDIO XFMR 600CT / 250CT TH |
3,704 | - |
|
Datasheet | 107 | Bulk | Active | 1.52:1 | 600CT | 250CT | 60Ohm | 40Ohm | Miniature Epoxy Potted | 300Hz ~ 50kHz | ±1.5dB | 100VRMS | - | - | 150mW | - | - | Through Hole | 0.630" L x 0.586" W (16.00mm x 14.88mm) | 0.630" (16.00mm) | PC Pin |
|
|
144SAUDIO XFMR 20K / 8 CHAS MNT |
2,235 | - |
|
Datasheet | 144 | Bulk | Active | - | 20k | 8 | 1.24kOhm | 900mOhm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 50mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
144PAUDIO XFMR 10K / 3.2 CHAS MNT |
2,420 | - |
|
Datasheet | 144 | Bulk | Active | - | 10k | 3.2 | 575Ohm | 500mOhm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 50mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
101PAUDIO XFMR 300CT / 50CT TH |
3,273 | - |
|
Datasheet | 101 | Bulk | Active | - | 300CT | 50CT | 20.4Ohm | 4.8Ohm | Miniature Epoxy Potted | 200Hz ~ 100kHz | ±0.5dB | - | - | - | 100mW | - | - | Through Hole | 0.450" L x 0.450" W (11.43mm x 11.43mm) | 0.480" (12.19mm) | PC Pin |
|
|
107TAUDIO XFMR 10KCT / 10KCT TH |
2,507 | - |
|
Datasheet | 107 | Bulk | Active | 1:1 | 10kCT | 10kCT | 690Ohm | 680Ohm | Miniature Epoxy Potted | 300Hz ~ 50kHz | ±1.5dB | 100VRMS | - | - | 150mW | - | - | Through Hole | 0.630" L x 0.586" W (16.00mm x 14.88mm) | 0.630" (16.00mm) | PC Pin |
|
146BAUDIO XFMR 48CT / 3.2 CHAS MNT |
1,574 | - |
|
Datasheet | 146 | Bulk | Active | - | 48CT | 3.2 | 2.4Ohm | 300mOhm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 700mW | - | - | Chassis Mount | 1.630" L x 0.880" W (41.40mm x 22.35mm) | 0.810" (20.57mm) | Wire Leads |
|
|
146FAUDIO XFMR 250CT / 3.2 CHAS MNT |
1,497 | - |
|
Datasheet | 146 | Bulk | Active | - | 250CT | 3.2 | 11Ohm | 300mOhm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 700mW | - | - | Chassis Mount | 1.630" L x 0.880" W (41.40mm x 22.35mm) | 0.810" (20.57mm) | Wire Leads |
Audio Transformers FAQ
Common questions about filtering, comparing and sourcing Audio Transformers components.
How can I narrow the Audio Transformers selection?
Use the available manufacturer and technical parameter filters to reduce the product list. Compare the remaining part numbers against your electrical, package and application requirements.
Should I confirm the datasheet before selecting a part?
Yes. Always review the manufacturer datasheet to confirm ratings, package, operating conditions and other technical details before finalizing a component for your design.
Can Winsun (HK) Electronics help source a specific Audio Transformers part number?
Yes. Send the exact manufacturer part number and required quantity for availability, lead-time and quotation support.
Do you support BOM, shortage or alternative-part requirements?
Yes. You can submit a BOM or shortage list for sourcing assistance. Where appropriate, our team can also help review possible alternative-part options.
