Audio Transformers
Use the filters and product table below to compare Audio Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Turns Ratio - Primary:Secondary | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) | DC Resistance (DCR) - Primary | DC Resistance (DCR) - Secondary | Transformer Type | Frequency Range | Frequency Response | Voltage - Isolation | Insertion Loss | Return Loss | Power Level | Operating Temperature | Approval Agency | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
560NXFMR 600 150/150 / 40K 10K/10K |
1,120 | - |
|
Datasheet | 560 | Bulk | Active | - | 600, 150/150 | 40k, 10k/10k | - | - | Broadcast Quality | 30Hz ~ 30kHz | ±1dB | - | 1dB Max | - | - | - | - | Through Hole | 1.330" L x 1.640" W (33.78mm x 41.66mm) | 0.850" (21.59mm) | PC Pin |
|
140QEXAUDIO XFMR 600CT / 600CT CHAS MT |
2,514 | - |
|
Datasheet | 140EX | Bulk | Active | 1:1 | 600CT | 600CT | 72.4Ohm | 72.4Ohm | - | 20Hz ~ 20kHz | ±1dB | 500Vrms | 1.1dB Typ | 20dB Typ | 10dB | - | - | Chassis Mount | 1.250" Dia (31.75mm) | 1.000" (25.40mm) | Screw Terminal |
|
1609XFMR 10KCT / 4, 8, 16 CHAS MNT |
3,801 | - |
|
Datasheet | 1600 | Bulk | Active | - | 10kCT | 4, 8, 16 | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | - | ±1dB | - | 10W | - | - | Chassis Mount | 2.750" L x 2.500" W (69.85mm x 63.50mm) | 3.060" (77.72mm) | Wire Leads |
|
1608AXFMR 8KCT / 4, 8, 16 CHAS MNT |
1,972 | - |
|
Datasheet | A | Box | Active | - | 8kCT | 4, 8, 16 | 91.31Ohm, 102.3Ohm | 321mOhm, 365mOhm, 476mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | 2000V @ 1 Second | - | - | 10W | - | - | Chassis Mount | 2.750" L x 2.500" W (69.85mm x 63.50mm) | 3.060" (77.72mm) | Wire Leads |
|
|
1650FAXFMR 7.6KCT / 4, 8, 16 CHAS MNT |
3,232 | - |
|
Datasheet | A | Box | Active | - | 7.6kCT | 4, 8, 16 | 92.16Ohm, 102.8Ohm | 210mOhm, 239mOhm, 309mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | 2000V @ 1 Second | - | - | 25W | - | - | Chassis Mount | 3.500" L x 2.500" W (88.90mm x 63.50mm) | 3.060" (77.72mm) | Wire Leads |
|
1650NXFMR 4.3KCT / 4, 8, 16 CHAS MNT |
2,645 | - |
|
Datasheet | 1600 | Bulk | Active | - | 4.3kCT | 4, 8, 16 | 82.5Ohm | 232mOhm, 270mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | 2000V @ 1 Second | ±1dB | - | 60W | - | - | Chassis Mount | 4.185" L x 3.125" W (106.30mm x 79.38mm) | 3.859" (98.02mm) | Wire Leads |
|
|
1650RXFMR 5KCT / 4, 8, 16 CHAS MNT |
4,822 | - |
|
Datasheet | 1600 | Bulk | Active | - | 5kCT | 4, 8, 16 | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 30Hz ~ 30kHz | ±1dB | - | ±1dB | 1650R | 100W | - | - | Chassis Mount | 4.250" L x 3.750" W (107.95mm x 95.25mm) | 4.560" (115.82mm) | Wire Leads |
|
148EAUDIO XFMR 500 / 500 125/125 TH |
3,339 | - |
|
Datasheet | 148 | Bulk | Active | - | 500 | 500, 125/125 | 79Ohm | 60Ohm | Economical Open Type | 200Hz ~ 15kHz | ±1dB | - | 0.5dB | - | 75mW | - | - | Through Hole | 0.820" L x 0.680" W (20.83mm x 17.27mm) | 0.690" (17.53mm) | PC Pin |
|
106CAUDIO XFMR 50K / 1.5KCT TH |
1,173 | - |
|
Datasheet | 106 | Bulk | Active | - | 50k | 1.5kCT | 2.4kOhm | 52Ohm | Miniature Epoxy Potted | 60Hz | -1dB | 200V | 1dB | - | 10mW | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
|
148TAUDIO XFMR 500CT / 3.2 TH |
4,330 | - |
|
Datasheet | 148 | Bulk | Active | - | 500CT | 3.2 | 41Ohm | 340mOhm | Economical Open Type | 200Hz ~ 15kHz | ±1dB | - | 0.5dB | - | 300mW | - | - | Through Hole | 0.820" L x 0.680" W (20.83mm x 17.27mm) | 0.690" (17.53mm) | PC Pin |
