Fixed Inductors
Browse available Fixed Inductors part numbers with manufacturer references, stock information, pricing, datasheets and key specifications. Use the table below to compare options for your project.
For BOM, shortage or hard-to-find requirements, send your part number and quantity to Winsun (HK) Electronics for availability, lead-time and quotation support.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RB5480-1-102K-RC1000UH 10% RADIAL POWER CHOKE |
4,641 | - |
|
Datasheet | - | Radial, Vertical Cylinder | Bag | Active | - | - | 1 mH | ±10% | 60 mA | 92mA | Unshielded | 5.5Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.225" Dia (5.72mm) | 0.340" (8.64mm) |
|
RDC60-223K-RC22000UH 10% RADIAL DRUM CORE |
1,285 | - |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core, Wirewound | - | 22 mH | ±10% | 2 A | 1.8A | Unshielded | 2.74Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
RB5480-4-271K-RC270UH 10% RADIAL POWER CHOKE |
3,503 | - |
|
Datasheet | - | Radial, Vertical Cylinder | Bag | Active | - | - | 270 µH | ±10% | 1.3 A | 1.75A | Unshielded | 270mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.450" Dia (11.43mm) | 0.760" (19.30mm) |
|
RB5480-5-560K-RC56UH 10% RADIAL POWER CHOKE |
4,660 | - |
|
Datasheet | - | Radial, Vertical Cylinder | Bag | Active | - | - | 56 µH | ±10% | 4 A | 2.5A | Unshielded | 35mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.625" Dia (15.88mm) | 0.750" (19.05mm) |
|
|
RDC60-101K-RC100UH 10% RADIAL DRUM CORE |
3,790 | - |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core, Wirewound | - | 100 µH | ±10% | 27 A | 26.5A | Unshielded | 14mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
|
RDC60-121K-RC120UH 10% RADIAL DRUM CORE |
3,972 | - |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core, Wirewound | - | 120 µH | ±10% | 27 A | 24.5A | Unshielded | 15mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
|
RDC60-391K-RC390UH 10% RADIAL DRUM CORE |
3,488 | - |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core, Wirewound | - | 390 µH | ±10% | 13.5 A | 13.6A | Unshielded | 55mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
|
RDC60-273K-RC27000UH 10% RADIAL DRUM CORE |
4,527 | - |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core, Wirewound | - | 27 mH | ±10% | 1.7 A | 1.6A | Unshielded | 3.71Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
|
RDC60-331K-RC330UH 10% RADIAL DRUM CORE |
3,171 | - |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core, Wirewound | - | 330 µH | ±10% | 17 A | 14.8A | Unshielded | 40mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
|
RB5480-5-332K-RC3300UH 10% RADIAL POWER CHOKE |
1,272 | - |
|
Datasheet | - | Radial, Vertical Cylinder | Tray | Active | - | - | 3.3 mH | ±10% | 620 mA | 360mA | Unshielded | 1.8Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.625" Dia (15.88mm) | 0.750" (19.05mm) |
|
PCSV80-100M-RC10UH 20% PWR CHIP INDUCTOR |
3,851 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 10 µH | ±20% | 3.8 A | 4.3A | Shielded | 38mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
PCSV80-330M-RC33UH 20% SHIELDED PWR INDUCTOR |
2,438 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 33 µH | ±20% | 2 A | 2.3A | Shielded | 110mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
PCSV80-150M-RC15UH 20% SHIELDED PWR INDUCTOR |
3,639 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 15 µH | ±20% | 3.2 A | 3.6A | Shielded | 50mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
PCSV80-3R3M-RC3.3UH 20% SHIELDED PWR INDUCTOR |
1,881 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 3.3 µH | ±20% | 6 A | 7.5A | Shielded | 15mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
PCSV54-100M-RC10UH 20% SMD PWR CHIP INDUCTOR |
1,486 | - |
|
Datasheet | - | 2020 (5050 Metric) | Tape & Reel (TR) | Active | - | - | 10 µH | ±20% | 2.2 A | 2.8A | Shielded | 60mOhm | - | - | - | -25°C ~ 105°C | 100 kHz | - | Surface Mount | 2020 | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.165" (4.20mm) |
|
|
PCSV80-2R0M-RC2.0UH 20% SHIELDED PWR INDUCTOR |
4,791 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 2 µH | ±20% | 7.4 A | 9.6A | Shielded | 11mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
PCSV54-470M-RC47UH 20% SMD PWR CHIP INDUCTOR |
2,497 | - |
|
Datasheet | - | 2020 (5050 Metric) | Tape & Reel (TR) | Active | - | - | 47 µH | ±20% | 900 mA | 1.2A | Shielded | 310mOhm | - | - | - | -25°C ~ 105°C | 100 kHz | - | Surface Mount | 2020 | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.165" (4.20mm) |
|
|
PCSV80-121M-RC120UH 20% SHIELDED PWR INDUCTOR |
1,111 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 121 µH | ±20% | 1 A | 1.1A | Shielded | 425mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
PCSV80-6R8M-RC6.8UH 20% SHIELDED PWR INDUCTOR |
1,063 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 6.8 µH | ±20% | 5.1 A | 5.4A | Shielded | 25mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
PCSV80-4R7M-RC4.7UH 20% SHIELDED PWR INDUCTOR |
4,985 | - |
|
Datasheet | - | 3131 (8080 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 4.7 µH | ±20% | 5.5 A | 6A | Shielded | 18mOhm | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 3131 | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
Fixed Inductors FAQ
Common questions about selecting, comparing and sourcing Fixed Inductors components through Winsun (HK) Electronics.
What should I check when selecting Fixed Inductors components?
Compare the manufacturer part number, electrical specifications, package, operating conditions and application requirements. The product datasheet should be used to confirm technical suitability.
Can Winsun help source specific Fixed Inductors part numbers?
Yes. Send the exact part number, manufacturer and required quantity. Winsun (HK) Electronics can assist with availability checks, quotation support and sourcing options based on your requirement.
Do you support shortage, obsolete or hard-to-find Fixed Inductors parts?
Yes. Our sourcing team can review shortage and obsolete-part requirements and help check available supply channels or possible alternatives when appropriate.
How do I request a quote for Fixed Inductors components?
Submit an RFQ with the part number, manufacturer, quantity and target delivery requirement. Our sales team will review your request and follow up with current sourcing information.
