Pulse Transformers
Use the filters and product table below to compare Pulse Transformers components by manufacturer, availability, pricing reference and technical specifications. Review datasheets and key parameters to narrow the selection for your application.
If you already have a target part number, package, rating or quantity, send the requirement to Winsun (HK) Electronics for availability checks, BOM sourcing, shortage support and quotation assistance.
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HX5014NLMODULE DL GIGABIT ETHER LAN 48P |
424 | - |
|
Datasheet | - | Tube | Active | LAN 1000 Base-T | - | - | 1CT:1CT | Surface Mount | 1.095" L x 0.480" W (27.81mm x 12.19mm) | 0.295" (7.49mm) | -40°C ~ 85°C | - | - |
|
HX4019NLTRANSF MOD 2.5G 4CH 60W POE |
180 | - |
|
Datasheet | - | Tube | Active | General Purpose | 150µH | - | 1:1 | Surface Mount | 0.715" L x 0.480" W (18.16mm x 12.20mm) | 0.260" (6.60mm) | - | - | - |
|
|
HX5014NLTTRANSFORMER MODULE GIGABIT 2PORT |
369 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | - | - | 1:1 | Surface Mount | 1.095" L x 0.480" W (27.81mm x 12.19mm) | 0.295" (7.49mm) | -40°C ~ 85°C | - | - |
|
PM2180.011NLTXFMR GATE-DR 1CT:1CT SM NPB |
2,533 | - |
|
Datasheet | PM2180.XXXNL | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 1.02mH | 22VµS | 1CT:1CT | Surface Mount | 0.319" L x 0.280" W (8.10mm x 7.10mm) | 0.200" (5.08mm) | -40°C ~ 125°C | - | - |
|
PH9085.021NLTIND PWR 3.0X3.0X1.2 1.16MH SMT |
1,525 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | - | - | - | - | Surface Mount | 0.319" L x 0.280" W (8.10mm x 7.10mm) | 0.200" (5.08mm) | - | - | - |
|
HM2106NLTMDL, SIN, XFMR, 1:1, 4.3KV, SMT, |
610 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | - | 135µH | - | 1:1 | Surface Mount | 0.335" L x 0.524" W (8.50mm x 13.31mm) | 0.226" (5.75mm) | -40°C ~ 125°C | - | - |
|
PA1277NLXFMR FLYBACK EP10 SMT |
561 | - |
|
Datasheet | PA1277NL | Tray | Active | Isolation and Data Interface (Encapsulated) | 20.4µH | - | - | Surface Mount | 0.600" L x 0.515" W (15.24mm x 13.08mm) | 0.451" (11.45mm) | - | - | - |
|
|
PM2180.012NLTXFMR GATE-DR 1CT:2CT SM NPB |
2,698 | - |
|
Datasheet | PM2180.XXXNL | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 1.02mH | 22VµS | 1CT:2CT | Surface Mount | 0.319" L x 0.280" W (8.10mm x 7.10mm) | 0.200" (5.08mm) | -40°C ~ 125°C | - | - |
|
PA2777NLPULSE XFMR 1:1 335.2UH |
872 | - |
|
Datasheet | - | Tray | Active | - | 335.2µH | 9.3VµS | 1:1 | Surface Mount | 0.291" L x 0.248" W (7.40mm x 6.30mm) | 0.232" (5.90mm) | -40°C ~ 130°C | - | - |
|
PA2005NLTPULSE XFMR 1:1:1 840UH |
5,058 | - |
|
Datasheet | - | Tape & Reel (TR) | Active | - | 840µH | 26VµS | 1:1:1 | Surface Mount | 0.340" L x 0.460" W (8.64mm x 11.68mm) | 0.160" (4.06mm) | -40°C ~ 130°C | - | - |
